IP67 M25 4 Pin 30A Outdoor Power Connector Quick Release Wire Connector
Jnicon 4Pin 20A Male Female Plug Waterproof M25 Circular Power Connectors
Description:
- Waterproof cable connector ip67
- Cable assembly supported
- industrial Electrical Plug
- Any quantity is welcome
- 5Pin male plug female plug
- TUV,UL,CUL,CE approval
- Panl mount connectors: for PCB, soldering
- circular outdoor power cable connectors
M25 waterproof round electrical connectors is the perfect solution to make your own waterproof connection cables easily. soldering is required and installation just takes a few minutes.
| Operation Parameters | |
| Voltage Rating | 600VAC max |
| Current Rating | 30A max |
| Min Wire Size OD | 6.5mm ~ 10mm |
| Max Wire Size OD | 10.5mm ~ 18mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 6.0mm2 |
| Technical Parameters | |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
Once assembled, the M25 waterproof ac power plug is easy to plug and play while keeping the elements and water out of splices and junctions. To disconnect, just unscrew the main body and pull apart the two ends.The M25 Waterproof conector has multiple waterproofing levels, consisting of o-rings, waterproof sealant, and flexible end seals designed to tighten and close when screwed together.
This M25 circular power connector has a waterproof rating of IP67. To assemble the M25 ip67 waterproof connector,only a Screwdriver is required to attach the two wires inside each main body. Once each side is connected, the wiring is fully protected from the elements.
If soldering version needed, its also avialble.
