NL6448AC33-A1D NLT 10.4INCH 370CD/M2 LCM 640×480 640×480RGB WLED TTL Operating Temp.: -30 ~ 80 °C INDUSTRIAL L
MOQ:
1PCS
Delivery Time:
2-3day
Brand:
NEC
Product Description
NLT NL6448AC33-A1D Summary
The NL6448AC33-A1D is a 10.4 inch diagonal a-Si TFT-LCD display panel product from NLT Technologies, Ltd. (hereafter called NLT), with an integral WLED backlight system, With LED Driver , without touch screen. It features an operating temperature range of -30 ~ 80°C , a storage temperature range of -30 ~ 80°C , and the maximal vibration level of 2.0G (19.6 m/s²).It's general features are summarized by Panelook in the following: Wide Temperature, WLED Backlight, Life ≥ 100K hours, With LED Driver, 180° Reverse, Matte . Based on its features, Panelook recommend that this model be applied to Industrial etc. According to the information stored in Panelook this model mass production on Q4, 2017 and last shippment on Q1, 2025, Now this model is discontinued. There are 8 items stock and 10 suppliers of this model on Panelook. We inputted this model's specification on May 15 2018 for the first time, and the latest update on Oct 25 2023. If you want to embed NL6448AC33-A1D LCM in your future product, Panelook strongly recommend that you should contact with NLT or it's agent to learn lateast production and specification detail. The NL6448AC33-A1D production status marked on Panelook.com is for reference only and should not be used as the basis for the user's decision making. All specification details are inputted by Panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.
NLT NL6448AC33-A1D Application Features
| Basic Information : | Brand | Model | Type | Model Alias |
|---|---|---|---|---|
| NL6448AC33-A1D | a-Si TFT-LCD , LCM | - | ||
| Reliability : | RoHS | Operating Temperature | Storage Temperature | Vibration Resistance |
| -30 ~ 80 °C | -30 ~ 80 °C | - | ||
| Designed For : |
|
|||
NLT NL6448AC33-A1D Mechanical Features
| Panel Size : | 10.4 inch | |||
|---|---|---|---|---|
| Pixel Features : | Resolution | Pixel Arrangement | Dot Pitch (W×H) | Pixel Pitch (W×H) |
| 640(RGB)×480, VGA | RGB Vertical Stripe | 0.110×0.330 mm | 0.330×0.330 mm [76PPI] | |
| Mechanical Size : | Active Area (W×H) | Bezel Area (W×H) | Outline Dimension (W×H) | Outline Depth |
| 211.2×158.4 mm | - | 227.3×177.5 mm | 9.8 (Max.) mm | |
| Outline Features : | Form Style | Aspect Ratio | Orientation | Shape Style |
| Flat Rectangle | 4:3 (W : H) | Landscape type | ||
| Other Features : | Panel Cover | Weight | Surface | |
| - | 380g (Max.) | Antiglare | ||
NLT NL6448AC33-A1D Optical Features
| Basic Information : | Brightness | Operating Mode | Contrast Ratio |
|---|---|---|---|
| 370 cd/m² (Typ.) | TN, Normally White, Transmissive | 900:1 (Typ.) (Transmissive) | |
| Viewing Angle(L/R/U/D) | Viewing Direction | Response Speed | |
| 80/80/80/80 (Typ.)(CR≥10) | - | 18 (Typ.)(Tr+Td) (ms) | |
| Dispaly Color : | Color Temperature | Color Amount | White color Chromaticity |
| - | 262K (6-bit) | - |
NLT NL6448AC33-A1D Backlight Features
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | - | - | 100K(Typ.) | - | |
| Driver Electrical : | Current Input | Voltage Input | Consumption | |||
| - | 12.0V (Typ.) | |||||
