NL6448BC33-49 NLT 10.4INCH 200CD/M2 LCM 640×480 640×480RGB CCFL TTL Operating Temp.: 0 ~ 55 °C INDUSTRIAL LCD DISPLAY

Price Negotiable
Price: 50USD
MOQ: 1PCS
Delivery Time: 2-3 DAYS
Brand: NEC
Product Description

NEC NL6448BC33-49 Overview

The NL6448BC33-49 is a 10.4 inch diagonal a-Si TFT-LCD display panel product from NEC LCD Technologies, Ltd. (hereafter called NEC), with an integral CCFL backlight system, without backlight driver, without touch screen. It features an operating temperature range of 0 ~ 55°C , a storage temperature range of -25 ~ 75°C , and the maximal vibration level of 1.0G (9.8 m/s²).





NEC NL6448BC33-49 Application Details

Basic Detail :
Manufacturer

Model Name
NL6448BC33-49
Panel Type
a-Si TFT-LCD , LCM
Another Name
-
Panel Size
10.4 inch
Designed For

Maximum Ratings :
OP Temperature
0 ~ 55 °C
ST Temperature
-25 ~ 75 °C
RoHS

Vibration Level
1.0G (9.8 m/s²)
Features :



NEC NL6448BC33-49 Optical Details

Basic Detail :
Luminance
200 cd/m² (Typ.)
Contrast Ratio
300:1 (Typ.) (Transmissive)
Good View at
6 o'clock
Response Speed
10/40 (Typ.)(Tr/Td) ms
Viewing Angle
70/70/40/70 (Typ.)(CR≥10)
Operating Mode
TN, Normally White, Transmissive
Color Performance :
Chromaticity
Wx:0.313; Wy:0.329
Support Color
262K (6-bit)
Color Temperature
6485K
White Variation
1.25/1.45 (Typ./Max.)(5 points)



NEC NL6448BC33-49 Mechanical Details

Pixel Features :
Number of Pixel
640(RGB)×480, VGA
Arrangement
RGB Vertical Stripe
Dot Pitch(W×H)
0.110×0.330 mm
Pixel Pitch(W×H)
0.330×0.330 mm [76PPI]
Physical Size :
Active Viewing
211.2(W)×158.4(H) mm
Overall Dim.
243(W)×185.1(H) mm
Bezel Opening
216.2(W)×163.4(H) mm
Overall Depth
10.5±0.5 mm
Outline Features :
Form Shape
Flat Rectangle
Orientation
Landscape type
Aspect Ratio(W:H)
4:3
Shape Style

Fixation :
Face mounting holes (4 pcs) on left, right bezel
Other Detail :
Mass
530/550g (Typ./Max.)
Surface
Antiglare, Hard coating (2H)



NEC NL6448BC33-49 Interface Detail

Signal Electrical :
Input Current
300/200mA (Typ.)
Input Voltage
3.3/5.0V (Typ.)
Consumption
-
Signal Interface
Parallel RGB (1 ch, 6-bit)
Logic Voltage :
0≤VIL≤0.3VCC; 0.7VCC≤VIH≤VCC
Interface Features :
Position
-
Type
Connector
Interface Detail :
Brand
Model
Pitch
Pins
Amount
Pin Assignment
HRS
DF9C-31P-1V
1.0 mm
31 pins
1 pcs
DRGB-31P1C6B-010K



FAQ:

Q1: What's the quality of your LCD Panel?



A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.



Q2: What is your return and refund policy?



A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.



Q3: How long is the lead time?



A: The lead time is about 1-3 working days after receipt of payment.



Q4: How can I get the quotation?



A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
