T-55619GD065J-LW-ABN Kyocera 6.5INCH LCM 640×480RGB 750NITS WLED LVDS INDUSTRIAL LCD DISPLAY
Price:
Negotiable
MOQ:
1PCS
Delivery Time:
1-2day
Brand:
Kyocera
Product Description
OPTREX T-55619GD065J-LW-ABN Application Details
| Basic Information : | Brand | Model | T-55619GD065J-LW-ABN | |
|---|---|---|---|---|
| Type | LCM a-Si TFT-LCD | Used For | ||
| Screen Size | 6.5" | Alias | - | |
| Environment : | Storage Temp. | -20 ~~ 70 °C | Operating Temp. | -20 ~~ 70 °C |
| RoHS | Vibration | - |
OPTREX T-55619GD065J-LW-ABN Mechanical Details
| Pixel Features : | Resolution | 640(RGB)×480, VGA | Dot Pitch(mm) | 0.069×0.207 (H×V) |
|---|---|---|---|---|
| Pixel Format | RGB Vertical Stripe | Pixel Pitch(mm) | 0.207×0.207 (H×V) [122PPI] | |
| Mechanical Size : | Active Area(mm) | 132.48(H) × 99.36(V) | Bezel Area(mm) | 136.46(H) × 101.9(V) |
| Outline Dim.(mm) | 158(H) × 120.36(V) | Depth(mm) | 7.0/12.0 (Typ./Max.) | |
| Outline Features : | Form Style | Flat Rectangle | Outline Shape | |
| Aspect Ratio | 4:3 (H:V) | Orientation | Landscape type | |
| Mounting : | Face mounting holes | |||
| Other Spec : | Weight | 230g (Max.) | Treatment | Antiglare |
OPTREX T-55619GD065J-LW-ABN Optical Details
| Basic Information : | Luminance(cd/m²) | 750 (Typ.) | Contrast Ratio | 300:1 (Typ.) (Transmissive) |
|---|---|---|---|---|
| Viewing Angle | 55/55/30/60 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive | |
| Best View on | 6 o'clock | Response(ms) | 15/16 (Typ.)(Tr/Td) | |
| Color Performance : | White Coordinate | X:0.320; Y:0.350 | Display Colors | 262K (6-bit) |
| Color Temperature | 6022K | White Uniformity | 1.43 (Max.)(9 points) | |
| 1931 Color Gamlt : | NTSC Ratio | 39% | sRGB | 53% coverage |
| Adobe RGB | 40% coverage | DCI-P3 | 40% coverage | |
| Rec.2020 | 29% coverage | Remarks | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| Dispaly Performance : | Outdoor Visibility | Sunlight Readable | Transmissivity | - |
OPTREX T-55619GD065J-LW-ABN Electronics Details
| Frame Rate : | 60Hz |
|---|---|
| Reverse Scan : | Yes (180°) |
OPTREX T-55619GD065J-LW-ABN Interface Details
| Signal Electrical : | Voltage Supply | 3.3V (Typ.) | Current Supply | 310/465mA (Typ./Max.) | ||
|---|---|---|---|---|---|---|
| Signal Type : | LVDS (1 ch, 6-bit) | Signal Voltage | - | |||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| HRS | DF14A-20P-1.25H(56) | 1 pcs | 20 pins | 1.25 mm | LVDS-20P1C6B-010B | |
OPTREX T-55619GD065J-LW-ABN Backlight Details
| Backlight Features: | Shape | 2 strings | Type | WLED | Position | Edge light type |
|---|---|---|---|---|---|---|
| Replacement | - | Quantity | 6S2P | Life Time | 70K(Typ.) (Hours) | |
| Lamp Electrical : | Voltage Supply | 18.4/21.4V (Typ./Max.) | Current Supply | 60mA (Typ.) | ||
| Interface Features : | Position | - | Type | Connector | ||
| Interface Detail : | Brand | Model | Quantity | Pins | Pitch | Pin Configuration |
| JST | SM06B-SHLS-TF(LF)(SN) | 1 pcs | 6 pins | 1.0 mm | BLE-6PINS-AANNCC | |
| Backlight Driver : | No | |||||
FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
