DX255 DX258 DH255 Excavator Travel Device K9005007 K1011403A
Belparts DX255 DX258 DH255 Excavator Travel Device K9005007 K1011403A Final Drive
Product Description
| Product name | Belparts DX255 DX258 DH255 Excavator Travel Device K9005007 K1011403A Final Drive |
| Place of Origin: | China(mainland) |
| Model: | DX255 DX258 DH255 |
| Part number: | K9005007 K1011403A Final Drive |
| MOQ: | 1 PCS |
| Payment term: | T/T & Western Union.... |
| Delivery time: | Within 2 days after receiving the payment |
| Packing: | Standard exporting packing or as required |
Spare part K9005007 REDUCTION GEAR ASS'Y (Doosan)
| Part No | K9005007 |
| Part Name | REDUCTION GEAR ASS'Y |
| Weight | 172 kg |
Schemes of the spare part K9005007 REDUCTION GEAR ASS'Y
Number RG on the scheme, Qty 1
Models comprising the spare part K9005007 REDUCTION GEAR ASS'Y
CRAWLER EXCAVATOR
DX255LC; DX255LC (ERP);
EXCAVATOR
TXC255LC-2;
Aggregates comprising the spare part K9005007 REDUCTION GEAR ASS'Y
| Model | Section node |
|---|---|
| DX255LC (ERP) | HYDRAULIC PARTS / TRAVEL REDUCTION GEAR |
| DX255LC | HYDRAULIC PARTS / TRAVEL REDUCTION GEAR |
| TXC255LC-2 | HYDRAULIC PARTS / TRAVEL REDUCTION GEAR |
List of spare parts
| # | Part No | Part Name | Comment | Qty. | Price request |
|---|---|---|---|---|---|
| 15 | 1.115-00138 | RING | 1 | ||
| 19 | 1.414-00009 | COUPLING | 1 | ||
| 20 | 1.412-00164 | PLATE, THRUST | 2 | ||
| 23 | 1.180-00355 | RING, SEAL | 5 kg | 1 | |
| 24 | 1.109-00146 | BEARING, ANGULAR BALL | 7 kg | 2 | |
| 26 | 1.180-00512 | SEAL, FLOATING | 2 kg | 1 SET | |
| 29 | S8010230 | O-RING | 1 | ||
| 30 | 2181-1116D4 | PLUG, RECHECK | 97123-04111 | 3 | |
| 32 | S0561471 | BOLT, HEX M12X1.75X85 | 20 | ||
| 33 | S5110701 | WASHER, SPRING | 1 kg | 20 | |
| 34 | 1.123-00026 | PIN, PARALLEL | 3 | ||
| 36 | S6250200 | BALL, STELL | 1 | ||
| 39 | S8000081 | O-RING | 2 | ||
| 40 | S8003401 | O-RING | 1 | ||
| - | K1011413A | DEVICE, TRAVEL | 321 kg | 2 | |
| RG | K9005007 | REDUCTION GEAR ASS'Y | 172 kg | 1 | |
| RG1 | K9005008 | HUB ASS'Y | 1 | ||
| 1 | *NA00546 | HUB | SIS | 1 | |
| 4 | *NA00495 | GEAR, RING A | 1 | ||
| 27 | 1.123-00107 | PIN, PARALLEL D12X63 | 10 | ||
| RG2 | K9005010 | SPINDLE ASS'Y | 67 kg | 1 | |
| 2 | *NA01154 | SPINDLE | 1 | ||
| 8 | 1.404-00002 | GEAR, COUPLING | 8 kg | 1 | |
| 35 | S2224471 | BOLT, SOCKET M8X2.5X40 | 10 | ||
| 17 | 1.123-00034 | PIN | 10 | ||
| RG3 | 1.230-00053 | CARRIER ASS'Y | 33 kg | 1 | |
| 3 | 1.230-00054 | CARRIER | 29 kg | 1 | |
| 6 | 1.404-00007 | GEAR, CLUSTER | 9 kg | 3 | |
| 9 | 1.405-00121 | SHAFT, CLUSTER | 3 kg | 3 | |
| 14 | 1.114-00541 | COLLAR, THRUST | 6 | ||
| 25 | 1.109-00145 | BEARING, NEEDLE | 6 | ||
| 5 | 1.104-00003 | GAER, RING B | 17 kg | 1 | |
| 7 | 1.403-00111 | GEAR, SUN | 1 kg | 1 | |
| 12 | 1.540-00004 | PIECE, DISTANCE | 1 | ||
| 13 | 1.430-00030 | COVER | 15 kg | 1 |
