Aggregate 5mm 1.5Mpa 3500L/H Peristaltic Chemical Pump

Price Negotiable
Price: Negotiation
MOQ: 1 Set
Delivery Time: 10~30 Work Days
Brand: KEMING
Product Description

Own factory Industrial Hose Pump High Volume Rate Peristaltic Chemical Pump for Foam Concrete Block

Hose Pump Features:

1. No valve operation, no back flow, stable pumping flow, low fault rate.

2.Unique seal structure guarantees no leakage;

3. Strong self-priming ability, suction distance of water can reach up to 8 meters;

4.The pumped fluid is only in contact with the hose, so it can transport fluid materials with various viscosity, density, corrosion, abradability;

5. Convenient maintenance, less wearable parts (except extruded hose).

Hose Pump Application:

1. Architecture: mortar,plaster,cement paste,soil slurry,silt slurry,lime slurry,foamed concrete, architectural coating, refractory,accelerator,ooze,waste water,sewage and so on.

2. Agriculture: phosphate fertilizer,compound fertilizers,thick slurry, precipitated sludge.

3. Chemical: corrosive,acid,alkali,phosphate liquid,inorganic materials,crystalline liquid,suspending liquid,emulsion,resin,electroplate liquid,electrolyte solution,precipitate.

4. Mining: gold pulp,tailings,thick pulp,filling materials,underground drainage,adsorbent,slurry, mortar...

5. Paper industry: paper pulp, liquid sulfur.

6. Food and Beverage: oil, brew, milk, confiture, salad, syrup, chocolate.

7. Oil industry: drilling fluid,crude oil.

8. Cosmetics industry: toothpaste, emulsion, hair conditioner, face cream, facial oil.

9. Ceramic industry: ceramic germ plasma, slip glaze, glaze materials.

10. Others: pharmaceutical liquid,radioactive liquid,textile auxiliary,adhesion agent,glue,latex.

Technical Parameters:

Model
KH38C Hose Pump
Output
2000~3500 L/h
Rated pressure
1.5 MPa
Rev.
40~70 r/min
Hose length
1150 mm
Max. particle dia.
5 mm
Max. suction dist.
4 m
Motor power
2.2/ 3/ 4 KW
Reducer type
Gear reducer
Note:
Driven power could be driven by electric motor or diesel engine.
Various squeeze hoses are available for pumping different materials.
Customized pump is available.
