Precision Coil Tubing Bright Annealed,Industrial stainless steel tubing coil beer EN10217-7 TC1
Precision Coil Tubing Bright Annealed,Industrial stainless steel tubing coil beer EN10217-7 TC1
| EN | ASTM | Item Name | Finish |
| 1.4404 | TP316L | 6.00 X 1.0 mm TIG welded stainless steel coiled tubes, 1.4404, bright annealed, EN 10217-7 W2Rb |
Bright Annealed |
| 1.4404 | TP316L | 8.00 X 1.0 mm TIG welded stainless steel coiled tubes, 1.4404, bright annealed, EN 10217-7 W2Rb |
Bright Anneaeld |
| 1.4404 | TP316L | 10.00 X 1.0 mm TIG welded stainless steel coiled tubes, 1.4404, bright annealed, EN 10217-7 W2Rb |
Bright Annealed |
| 1.4404 | TP316L | 12.0 X 1.0 mm TIG welded stainless steel coiled tubes, 1.4404, bright annealed, EN 10217-7 W2Rb |
Bright Annealed |
| 1.4404 | TP316L | 6.35 X 0.89 mm TIG welded stainless steel coiled tubes, TP316L, bright annealed, ASTM A249 A269 |
Bright Annealed |
| 1.4404 | TP316L | 9.53 X 0.89 mm TIG welded stainless steel coiled tubes, TP316L, bright annealed, ASTM A249 A269 |
Bright Annealed |
| 1.4404 | TP316L | 12.7 X 0.89 mm TIG welded stainless steel coiled tubes, 1.4404, bright annealed, ASTM A249 A269 |
Bright Annealed |
| 1.4404 | TP316L | 6.35 X 1.24 mm TIG welded stainless steel coiled tubes, TP316L, bright annealed, ASTM A249 A269 |
Bright Annealed |
| 1.4404 | TP316L | 9.53 X 1.24 mm TIG welded stainless steel coiled tubes, TP316L, bright annealed, ASTM A249 A269 |
Bright Annealed |
| 1.4404 | TP316L |
12.7 X 1.24 mm |
Bright Annealed |
| 1.4404 | TP316L | 6.3M X 1.65 mm TIG welded stainless steel coiled tubes, TP316L, bright annealed, ASTM A249 A269 |
Bright Annealed |
| 1.4404 | TP316L | 9.53 X 1.65 mm TIG welded stainless steel coiled tubes, TP316L, bright annealed, ASTM A249 A269 |
Bright Annealed |
| 1.4404 | TP316L | 12.7 X 1.65 mm TIG welded stainless steel coiled tubes, TP316L, bright annealed, ASTM A249 A269 |
Bright Annealed |
Certificates & Inspection:
Third party inspection can be carried out by following independent inspection authorities:
|
|
|
|
|
|
|
|
|
|
Other customer specified inspection authorities, can be nominated by customers.
Certification of stainless + nickel tubes is generally to EN 10204. The actual certificate will depend on the tube offered but will either be 3.1 or 3.2. A 3.1 or 3.2 MTC means that the actual tubes or heat sold will have been tested and a Mill Test Certificate (MTC) will accompany the tubes.
EN 10204 3.1 Certification
3.1 is a certificate on all our tubing issued by the mill which declares that the tubes are in compliance with the specification and includes the test results. Test results are validated by the mill’s in - house test department which has to be independent of the manufacturing department.
EC Pressure Equipment Directive 97/23/EC ( PED )
Tubes certified to 3.1 or 3.2 are in conformity with the EC Pressure Equipment Directive 97/23/EC for main pressure-bearing parts in categories II, III and IV.
