Round High Purity Stainless Steel Tubing Mechanical Polished ASTM A213 A269
ASTM A213 A269 TP316/316L 1/2'' X 0.065'' X 20FT Mechanical Polished Seamless Stainless Steel Tubing
Features:
High-quality standard and special grade of MP seamless stainless steel tubing. Our 300 series has increased strength and corrosion resistance for applications in harsh environments, meeting the requirements for your stainless tube projects. ASTM standard specifications include A213 seamless tube, A269 welded tube, A511 seamless mechanical tube, with annealed and pickled then mechanical polished. Tube cutting and polishing services customize your order to job specifications.
Descriptions:
| Item Code: | SPS-A213-316L-0050-065-MP |
| Tube OD.: | 1/2'' |
| Wall: | 0.065'' |
| Length: | 20' |
| Material: | TP316/316L |
| Standard: | ASTM A213 / ASTM A269 / ASME SA213 |
| Finish: | MP / Mechanical Polished |
| Type: | Seamless Cold Drawn |
| Certification: | ISO9001 |
| Mill Test Certificate: | EN10204 3.1 |
| Packing: | Sleeved, Ends Capped, Wooden Boxed |
Chemical Compositions:
| Elements | 316L (wt%) |
| C / Max. | 0.035 |
| Mn / Max | 2.00 |
| P / Max | 0.045 |
| S / Max | 0.005 - 0.017 |
| Si / Max | 1.00 |
| Ni | 10.00 - 14.00 |
| Cr | 16.00 - 18.00 |
| Mo | N/A |
| Fe | Bal. |
| Cu | N/A |
| N | N/A |
Mechanical Properties:
| Grade |
Tensile Strength |
Yield Strength |
Elongation |
Hardness |
|
|
|
|
|
|
Quality Assurance:
Spezilla's MP stainless steel tubings are produced acc. to the following process and inspection to assure our quality:
Chemical Analysis:
A Plasma Emission Spectrometer is used to determine the composition of elements found in various metal alloys. This process is routinely used for alloy identification and verification of material as part of a full quantitative analysis. Corrosion resistance testing is performed on many different alloys and various media is used to confirm product integrity or aid in material selection.
Metallurgical Investigation:
Our trained staff provides microscopic and macroscopic services as well as metallurgical interpretation of results. Grain size determination, inclusion count, micro structure analysis, phase identification and weld integrity are just a few of the tests performed by our metallurgical staff.
Applications:
Spezilla's MP Stainless steel tubing is used for many industries that require resistance to high pressures, high temperatures, and corrosive environments. These include, but are not limited to: petrochemical, gas, nuclear, food and beverage, and chemical plants. Various wall thicknesses are available to suit a range of pressure requirements, and several different finishes are available to achieve the desired aesthetic.
1. Oil & Gas Extraction
2. Chemical & Petrochemical
3. Nuclear Power
4. Food & Beverage Processing
5. Automotive
6. Aerospace
