Precision Thin Wall TP304 316L Stainless Steel Tube , Cold Rolled Seamless Steel Pipe
Precision Thin Wall TP304 316LStainless Steel Tube , Cold Rolled Seamless Steel Pipe
Spezilla's ASTM A213 A269 TP316L welded precision stainless steel tubes are produced acc. to the following process and inspection to assure our quality:
1. Chemical Composition Analysis Test With 100% PMI.
2. Solution Annealing / Bright Annealed.
3. 100% Hydrostatic Test and 100% Eddy Current Test
4. Mechanical Tests includes Tension Test, Flattening Test, Flaring Test, Hardness Test.
5. Impact Test subject to Standard request.
6. Grain Size Test and Intergranular Corrosion Test.
7. Visual Test and Endoscope Test for Surface Quality Test
Typical Applications:
Hydraulic Tubing
Instrumentation Tubing
Typical Manufacturing Specifications:
ASTM A213
ASTM A269
Also individual customer specifications.
Quick Detail:
precision rolled stainless steel precision pipe tube
Type: stainless steel pipe,seamless stainless steel tube, welded stainless steel pipe
Production Technology: cold rolled,precision rolled,cold drawn.
Thin Wall Precision Stainless Steel Tubing , Cold Rolled Seamless Steel Pipe
Advantage:
• Advanced production and inspection equipment
• Top quality control system and service system
• Professional & Sincerity
• Competitive Price
• Good Reputation
• Timely Delivery
1. Products Specification
|
Commodity |
precision rolled stainless steel precision pipe tube |
|
Standard |
ASTM/AISI ,GB,JIS,DIN,EN,etc |
|
Material Grade |
TP304/304L, TP321/TP321H |
|
SUS304/304l, SUS316/316L, 304lL, 316L, 321, 316Ti,etc |
|
|
Outer Diameter |
6mm or as your request |
|
Thickness |
1mm or as your request |
|
Length |
<8m or as customers' request |
|
Tolerance |
According to the Standard |
|
Surface |
180G, 320G, 400G Satin / Hairline |
|
400G, 500G, 600G or 800G Mirror finish |
|
|
Application |
Petrochemical industry, chemical fertilizer industry, oil refining industry, oil and gas industry, light industry and food industry, pulp and paper industry, energy and environmental industries. |
|
Test |
UT,ET,HT RT, squash test, water pressure test, etc and others according to the standard |
|
Package |
Standard sea-worthy package or as buyers' requirement |
|
MOQ |
2 Metric Ton |
|
Price term |
FOB Shanghai or Ningbo |
2. Chemical Element Analysis
|
Type |
Chemical Composition(%) |
|||||||||
|
ASTM |
C |
Cr |
Ni |
Mn |
P |
S |
Mo |
Si |
Cu |
N |
|
TP304 |
≤0.08 |
18.0-20.0 |
8.0-11.0 |
≤2.00 |
≤0.045 |
≤0.030 |
- - - |
≤1.00 |
- - - |
- - - |
|
TP304L |
≤0.035 |
18.0-20.0 |
8.0-13.0 |
≤2.00 |
≤0.045 |
≤0.030 |
- - - |
≤1.00 |
- - - |
- - - |
|
TP304H |
0.04-0.10 |
18.0-20.0 |
8.0-11.0 |
≤2.00 |
≤0.045 |
≤0.030 |
- - - |
≤1.00 |
- - - |
- - - |
|
TP310S |
≤0.08 |
24.0-26.0 |
19.0-22.0 |
≤2.00 |
≤0.045 |
≤0.030 |
≤0.75 |
≤1.00 |
- - - |
- - - |
|
TP316 |
≤0.08 |
16.0-18.0 |
11.0-14.0 |
≤2.00 |
≤0.045 |
≤0.030 |
2.00-3.00 |
≤1.00 |
- - - |
- - - |
|
TP316L |
≤0.035 |
16.0-18.0 |
10.0-14.0 |
≤2.00 |
≤0.045 |
≤0.030 |
2.00-3.00 |
≤1.00 |
- - - |
- - - |
|
TP316N |
≤0.08 |
16.0-18.0 |
11.0-14.0 |
≤2.00 |
≤0.045 |
≤0.030 |
2.00-3.00 |
≤1.00 |
- - - |
0.10-0.16 |
|
TP317L |
≤0.035 |
18.0-20.0 |
11.0-15.0 |
≤2.00 |
≤0.045 |
≤0.030 |
3.0-4.0 |
≤1.00 |
- - - |
- - - |
|
TP321 |
≤0.08 |
17.0-19.0 |
9.0-12.0 |
≤2.00 |
≤0.045 |
≤0.030 |
- - - |
≤1.00 |
- - - |
≤0.10 |
|
TP321H |
0.04-0.10 |
17.0-19.0 |
9.0-12.0 |
≤2.00 |
≤0.045 |
≤0.030 |
- - - |
≤1.00 |
- - - |
- - - |
|
TP347 |
≤0.08 |
17.0-19.0 |
9.0-13.0 |
≤2.00 |
≤0.045 |
≤0.030 |
- - - |
≤1.00 |
- - - |
- - - |
3. About Samples
- We can provide samples production and delivery service.
- for present sample usually 3 to 5 days.
- the samples can be sent to your hand.
- As for any information about the sample or any specific requirements of the sample, please contact us via telephone, mail or online trade manager.
4. Payment terms
- we accept T/T, L/C.
- payment terms: 30% to 50% deposit, the balance before shipment or copy of BL.
5. Delivery
- Delivery time: 30days-40days after receiving the deposit
- Way: by sea, DHL, FEDEX, UPS, TNT,etc.
