Saving Time Dry Mortar Plant , Automatic Ready Mix Plaster Plant 20-25 T/H

Price Negotiable
Price: Negotiable
MOQ: 1 set
Delivery Time: 25working days after we got advanced payment
Brand: CINACHARM
Product Description

20-25T/H Dry Mortar Mixing Plant dry mortar mixer machine ready mix plaster plant dry mortar equipment





1. Advantage of 20-25t/h dry mortar mixing plant

1). In contrast to job-site mortars ,dry mortar is also called pre-mixed mortar ,which is produced in the factory with dedicated facilities on batching and blending of

ingredients in highly-controlled process .It can be used directly just by adding water in job site .

2). It has advantages of consistent quality ,controlled inventory ,saving time and labor cost .By

adding different chemical additives ,it has fine properties of bond ,thermal and acoustic insulation,

crack-resistance ,workability , Water-retention,wear-proof,anti-corrosion,etc.

3). Dry mortar can match different kinds of new construction materials by improving formulation.

These good properties not only improve building’s quality and life greatly,but also decrease the usage of mortar in a large degree.

4). The demand for dry mortar has increased rapidly due to its outstanding merit comparing with

the mortar mad in job-site.





2. Parameters of 20-25t/h dry mortar mixing plant

Model Automatic Dry mortar Production line
Capacity 20-25 t/h
Mixing system DWZ Double Shaft Paddle Mixer
Total power 96.5kw
Mortar Mixer DWZ2000 Double Shaft Paddle Mixer, 1 unit
Discharge capacity 1.56t per batch
Feeding capacity 1.56t per batch
Mixing cycle time 150S
Motor power 18.5kw
Air Cylinder QGB100*300
Total weight 2500kg
Overall dimension L*W*H 2170*1900*1550 mm
Pre-mixing hopper 2.0 m3 Pre-mixing hopper, 1 unit
Volume 2.0m3
Pneumatic Valve DN150
End Product Hopper 2.0 m3 End product hopper, 1 unit
Volume 2.0m3
Motor Power 7.5kw
Raw Material Storage System 100T Detachable Silo, 1 set
Silo Diameter 3.0m
Silo Height 9.0m
Silo Total Height 12.0m
Discharge Height 1.5-3.0m
Pneumatic Valve DN300
Weight 5.0 tons
Batching & Weighting System V=2m3 Batching Weighing Hopper, 1 unit
Volume 2.0m3
Motor power 4kw
Screw Conveyor LSY165*2800mm
Overall dimension L*W*H 3.2* 1.26 *1.7m
Conveying System LSY219 Screw Conveyor, 2 units
Tube Diameter 219mm
Spiral Diameter 180mm
Carrying Capacity 45t/h
Conveying Length 2-13m
Working Angle 0-45degree
Motor Power 11kw
Conveying System TD250 Bucket Elevator, 1 unit
Conveying Capacity 20-25 t/h
Lifting Speed 1.6 m/s
Motor power 15kw
Height(include the embeded part) 11.7m
Packing System Type & Quantity DGF-50B Automatic valve port packer, 2 units
Weighing scope 5~50kg
Capacity 10-15 t/h per unit
Power 3kw
