Cement Hollow Block Making Machine 11KW Fully Automatic Convenient Operation
Price:
Negotiable
MOQ:
1 set
Delivery Time:
7 working days after we got advanced payment
Brand:
CINACHARM
Product Description
Fully automatic cement hollow brick making machine concrete block machine cement concrete block making machine
| Model | QT4-22 Block machine |
QT4-22 Block machine |
QT4-26 Block machine |
QT4-35 Block machine |
QT4-40 Block machine |
| Cycle Time(s) | 22s | 22s | 26s | 35s | 40s |
| PCS/Mould (240*115*53mm) |
26pcs | 26pcs | 26pcs | 26pcs | 26pcs |
| PCS/Shift (240*115*53mm) |
45000pcs | 34000pcs | 28800pcs | 2500-800pcs | 18500pcs |
| Power(KW) | 19.5kw | 19.5KW | 14.25KW | 11KW | 9.55KW |
| Dimension(mm) | 3000*2200*2900 | 2950*2150*1600 | 2060*1730*2580 | 1120*1400*1700 | 1400*1050*2350 |
| Pallet Dimension(mm) | 850*550*30mm | 850*550*30mm | 880*550*30mm | 880*480*30mm | 850*550*30mm |
| Raw material Workshop(m2) |
450m2 | 400m2 | 400m2 | 300m2 | 300m2 |
| Working shed(m2) | 300m2 | 200m2 | 200m2 | 150m2 | 150m2 |
| Working site(m2) | 2500m2 | 2500m2 | 2500m2 | 1500m2 | 1000m2 |
| Power distribution(KW) | 50KW | 45KW | 42KW | 30KW | 25KW |
| Water consumption | 9t/day | 6t/day | 5t/day | 4t/day | 3t/day |
| Pallets needed (pcs) | 500-800pcs | 500-800pcs | 500-800pcs | 500pcs | 500pcs |
| Weight(ton) | 3T | 3.0t | 2.4t | 1.1t | 1t |
| Staff needed | 8~10 | 5~8 | 3~5 | 2~3 | 2~3 |
| Warranty(months) | 18 months | 18 months | 18 months | 18 months | 18 months |
Detailed Specs of cement concrete block making machine :
| Brief Introduction: | ||||||
| Our 2016new QT4-22 Brick Machinefor sale(QT4-22 ) are with simple and compact structure, convenient operation and easy maintenance. It demands litter manpower and investment, but makes high output and quick ROI (return on investment). Especially suitable to produce standard bricks, hollow bricks, pavers, etc. The strength of which is higher than that of clay bricks. Various types of blocks can be produced with different molds. Therefore, It is an ideal choice for enterprises with small investment. | ||||||
| Main Specs: | ||||||
| Environmental protection | Confirms to the international environmental protection standard | |||||
| General power | 19.5kw | |||||
| Average power consumption | 20KW/h | |||||
| Average water consumption | 9T/day | |||||
| Land area | 2500m2 totally | |||||
| Equipment list: | ||||||
| Name of the item | Quantity | Remarks | ||||
| 2016new QT4-22 Brick Machinefor sale(QT4-22 ) | 1 | |||||
| Mixer | 1 | JW350 | ||||
| Belt conveyor | 1 | 8m | ||||
| Free mould | 1 | |||||
| Pallets | 500-800pcs | Upon ur request | ||||
| Block trolley | 1 | |||||
