810×480×860 500A 120kw AC380 Digital Welding Machine
Price:
USD+5000-50000+Unit
MOQ:
1 Unit
Delivery Time:
15-30 Days
Brand:
JINGHUA
Product Description
Welding Machine, Arc Inverter Welder, MIG Inverter Welder, TIG Inverter Welder
Instruction
· IGBT Tehnology
· Excellent TIG weld characteristics
· Generator compatible, idea for site use
· Peak current control mode, reliable quality and efficiency
· High speed pulse to adjust the arc focus, reduce distortion and increase travel speed
· Pre-set digital meter with hold function for fully procedured work
· Thrust function is added, transition performance of melt drip can be improved during welding
· Full power even in the case of voltage fluctuation and when using long cables
· Easy operation, one knob adjust
Specification
| Description | ZX5-400 | ZX5-500 | ZX5-630 |
| Input Voltage (V) | Three Phase AC380 | Three Phase AC380 | Three Phase AC380 |
| Rated Input Capacity (KVA) | 23 | 30 | 47 |
| Input Frequency (Hz) | 50/60 | 50/60 | 50/60 |
| Output Current Range (A) | 40-400 | 50-500 | 60-630 |
| Output Voltage (V) | 63 | 63 | 72 |
| Rated Duty Cycle (%) | 60 | 60 | 60 |
| Weight (KG) | 160 | 200 | 280 |
| Dimension (mm) | 779×450×779 | 810×480×860 | 810×480×860 |
