5500Mm Hardfacing Welding Machine For Steel Industries
Automatic Hardfacing System
Product Description
JH-350S application fields cover cement, power, steel, mining, petrochemical and other industries, for large vertical mill,coal mill, continuous casting roller, crusher, roller press and other wear resistance equipment wear liner to repair hard surface .The equipment adopts digital system control and supports triaxial curve interpolation welding, air gouging and other functions.
Our hardfacing machine is our new generation automatic welding equipment with multi purposes and high performance. This hardfacing equipment has the advantages of stable overlaying function, easy to operate and convenient in installation.
Characteristics
1. This automatic welding equipment can be applied to arc welding, submerged arc welding, gas shielded-arc welding, swing arc welding, etc.
2. Our automatic welding equipment can realize interactive operation through using TECO touch screen, human-machine interface and wireless remote control.
3. This hardfacing machine is highly-effective in real-time monitoring of operation process, production, welding time, and fault.
4. The aluminum alloy trolley and arm are designed by adopting a specially-designed turnover mechanism, and the welding head adopts universal adjusting lever. When the angle and height position is adjusted, this hardfacing equipment can be quickly debugged and installed.
Specification
| Manipulator | Heavy-duty motorized cross-slides |
| Turntable | 6 foot diameter table, 15 ton capacity with slip ring |
| Standard Power Source | Miller Maxstar 700 with Coolmate 3.5 cooler, Maxstar 200 DX |
| Optional Power Source | Other power sources are available |
| Maximum Height Bore Depth | Up to 78.7 in (2000 mm) depending on torch type and vertical slides used |
| Minimum Weldable Bore | 1.77 in (45 mm) diameter |
| Water Cooled TIG Torch | Various fixed and adjustable-angle torch heads available |
| Welding Speed | 7.87 in/min to 17.7 in/min (20 to 45 cm/min) |
| Air Pressure | Requires 3-4 bar / 45-60 psi |
| Control | KEY 1250 PLC Controller |
| Control Functions | Controlled by 15 in TFT HMI or remote pendant |
| Input Power Miller Cooler | Coolmate 3.5 - 115 VAC 50/60 Hz (from power source) |
| Overall Height | 216.5 in (5500 mm) |
| Shipping Weight | 21,054 lb (9550 kg) complete system |
