Arched Trapezoidal Sheet Roll Forming Machin Efficienty Width 835 / 828 / 840mm
Arched Trapezoidal Sheet Roll Forming Machin Efficienty Width 835 / 828 / 840mm
| configurations | manual decoiler, main machine of roll forming, cutting device, output table, electric motor, PLC control system | ||||
| Material | processing material | Colored Steel plate, Galvanized Board, Aluminum Plate | |||
| thickness | 0.3mm-0.8mm | ||||
| Efficienty width | 835/828/840mm | ||||
| Coil width | 1000mm | ||||
| Manual decoiler | The maximum load capacity:5 ton | Expand by band | |||
| The coil inside diameter:450-550mm | |||||
| Suitable Coil width:1250mm | |||||
| Main Forming machine | Forming steps | 13steps | |||
| Shaft diameter | 70 mm | ||||
| Thick of arch frame | 16mm | ||||
| Frame body | High strength steel pipe weld with color steel sheet cover | ||||
| roller material | 45# steel | ||||
| shaft material | 45# steel | ||||
| cutter material | Cr12 mold steel with quenched treatment | ||||
| Transmission | By 1” chain | ||||
| Work speed | 20-25m/min | ||||
| Hydraulic system | Automatic hydraulic cutting after forming, without wasting. | ||||
| Control Device | PLC control | ||||
| Operating mode | Button+touch screen | ||||
| Total power | 4 kw | ||||
| Main body color | Blue and orange(or as required) | ||||
| Voltage | 380v/50hz/3ph(or as required) | ||||
A. If buyers visit our factory and check the machine, we will teach you how to install and use the machine,
and also trainyour workers/technician face to face.
B. Without visiting, we will send you user manual and video to teach you to install and operate.
C. If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
After service
A. One year guarantee for whole machine.
B. 24 hours technical support by email or phone call.
C. If there is any problem found of the machine, we will repair it for free in one year.
