Professional Downspout Roll Forming Machine Dimension 7.8 * 1.4 * 1.3m Easy Operation
Professional Downspout Roll Forming Machine Dimension 7.8 * 1.4 * 1.3m Easy Operation
machine specifications:
| Product name |
Gutter machine |
|||
|
NO. |
Items |
Parameters |
Remark |
|
|
1 |
Suitable
Material |
Type |
PPGI / GI / GL/AL |
|
|
Width |
200-500mm |
Custom |
||
|
Thickness |
0.40-0.70mm |
|||
|
2 |
Product Specifications |
Length |
Any length |
Programmed |
|
Length Tolerance |
±2mm/6m |
|||
|
3 |
Working Speed |
25 m/min |
Standard machine |
|
|
4 |
Control System |
Mitsubishi/Siemens PLC& transducer |
Custom |
|
|
5 |
Total Power |
About 10KW |
||
|
6 |
Total Weight |
About 6T |
Up to final design |
|
Material of main equipment:
Roller material: high grade NO.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm.
Active shaft material: high grade NO.45 carbon wrought steel at diameter 72mm.
Cutting blade: Cr12 mould steel with quenched treatment.
They are widely used as the roof of garden like factory, hotel, exhibition center, villa, civil construction, etc.
features of the production line:
1) Professional designing for manufactures roofing & walling
2) Automatically continually manufactures high quality product with PLC.
3) Easy operation : Directly input the data on the touchable screen
4) Customers decide the profile of products.
5) Saving time and cost owing to high speed running with hydraulic system.
6) One year warranty.
