2800rpm Excavator Vibro Hammer Q345 sheet pile vibratory hammer
2800rpm Excavator Vibro Hammer Q345 Sheet Pile Vibratory Hammer
High Efficient Excavator Vibro Hammer / Sheet Pile Vibratory Hammer
Products application
The efficient of vibration pile method is higher than other methods. It is mainly applied to steel sheet pile, steel pipe pile and long slender concrete precast pile within 8 meters. This pile driving method is the most suitable for working in sand and poorer effect in the clay which must select higher power model machines.
Performance parameter
Model | V-250D | V-300E | V-330E | V-350E | V-400D | V-450B | V-500A |
Vibration frequency(rpm) | 2800 | 3000 | 3000 | 3000 | 2600 | 2600 | 2600 |
Vibrating force(T) | 39.5 | 48 | 51 | 53.4 | 55.5 | 58 | 63 |
Hydraulic system operating pressure(Bar) | 300 | 300 | 300 | 300 | 300 | 300 | 300 |
Hydraulic system flow demand(Lpm) | 175 | 240 | 270 | 270 | 280 | 300 | 320 |
Main body weight(T) | 1.55 | 1.65 | 1.65 | 1.8 | 2 | 2.05 | 2.1 |
Apply to excavator weight(T) | 20-24 | 24-30 | 30-35 | 35-40 | 38-42 | 40-45 | 48< |
Clip mouth weight(kg) | C15:455kg; C16E:530kg; C18E:578kg C30B:455kg; C35B:530kg | ||||||
Assistant arm weight(kg) | A200:500kg; A250B:600kg A350:900kg | ||||||
