12000 TPD Max 5 R / Min Cement Plant Equipments cement rotary kiln
Price:
negotiable
MOQ:
1 Sets
Delivery Time:
Negotiable
Brand:
CITIC LK
Product Description
Products Description
1,000,000Tons/Year Cement Grinding Plant:
1,000,000Tons/Year Cement Grinding Plant:
In this 1,000,000t/y cement grinding plant, clinker and slag are ground separately. PFG120-50 rolling machine and Φ3.2m×13m cement mill are used in clinker ginding. Φ3.2m×13m ginding machine and high-efficiency powder separator are used in slag grinding.
This plant features are high quality, high productivity and low consumption.
In this 1,000,000t/y cement grinding plant, clinker and slag are ground separately. PFG120-50 rolling machine and Φ3.2m×13m cement mill are used in clinker ginding. Φ3.2m×13m ginding machine and high-efficiency powder separator are used in slag grinding.
This plant features are high quality, high productivity and low consumption.
Cement Rotary Kiln Specification Wet and Dry Cement Rotary Kiln
| Product specifications(m) | Kiln dimensions | Capacity(t/d) | Rotation speed(r/min) | Motor power(kw) | Total weight(t) | ||
| Diameter(m) | Length(m) | Obliquity(%) | |||||
| Φ2.5×40 | 2.5 | 40 | 3.5 | 180 | 0.44-2.44 | 55 | 149.61 |
| Φ2.5×50 | 2.5 | 50 | 3 | 200 | 0.62-1.86 | 55 | 187.37 |
| Φ2.5×54 | 2.5 | 54 | 3.5 | 204 | 0.48-1.45 | 55 | 196.29 |
| Φ2.7×42 | 2.7 | 42 | 3.5 | 320 | 0.10-1.52 | 55 | 198.5 |
| Φ2.8×44 | 2.8 | 44 | 3.5 | 400 | 0.437-2.18 | 55 | 201.58 |
| Φ3.0×45 | 3 | 45 | 3.5 | 500 | 0.5-2.47 | 75 | 210.94 |
| Φ3.0×48 | 3 | 48 | 3.5 | 700 | 0.6-3.48 | 100 | 237 |
| Φ3.0×60 | 3 | 60 | 3.5 | 800 | 0.3-2 | 100 | 310 |
| Φ3.2×50 | 3.2 | 50 | 4 | 1000 | 0.6-3 | 125 | 278 |
| Φ3.3×52 | 3.3 | 52 | 3.5 | 1300 | 0.266-2.66 | 125 | 283 |
| Φ3.5×54 | 3.5 | 54 | 3.5 | 1500 | 0.55-3.4 | 220 | 363 |
| Φ3.6×70 | 3.6 | 70 | 3.5 | 1800 | 0.25-1.25 | 125 | 419 |
| Φ4.0×56 | 4 | 56 | 4 | 2300 | 0.41-4.07 | 315 | 456 |
| Φ4.0×60 | 4 | 60 | 3.5 | 2500 | 0.396-3.96 | 315 | 510 |
| Φ4.2×60 | 4.2 | 60 | 4 | 2750 | 0.4-3.98 | 375 | 633 |
| Φ4.3×60 | 4.3 | 60 | 3.5 | 3200 | 0.396-3.96 | 375 | 583 |
| Φ4.5×66 | 4.5 | 66 | 3.5 | 4000 | 0.41-4.1 | 560 | 710.4 |
| Φ4.7×74 | 4.7 | 74 | 4 | 4500 | 0.35-4 | 630 | 849 |
| Φ4.8×74 | 4.8 | 74 | 4 | 5000 | 0.396-3.96 | 630 | 899 |
| Φ5.0×74 | 5 | 74 | 4 | 6000 | 0.35-4 | 710 | 944 |
| Φ5.6×87 | 5.6 | 87 | 4 | 8000 | Max4.23 | 800 | 1265 |
| Φ6.0×95 | 6 | 95 | 4 | 10000 | Max5 | 950×2 | 1659 |
Process Flow Design of 1,000,000Tons/Year Cement Grinding Plant:
1. Designing of Clinker Grinding Production Line
After gypsum, clinker and limestone are measured by the belt weigher, they will be mixed together in accordance with particular
proportions, and then sent to the stable weighing warehouse. During this process, magnetic metals are removed by the iron remover
from these materials. Then mixed materials will be sent into the rolling machine to be crushed. After crushed, they will be sent
to the powder separator, in which coarse powder will be sent back to the griding mill while the fine one will be sent to the
elevator for finished products. Finally, they will be sent to finished product storage. Meanwhile, dusty gas from the grinding
mill will be purified by the environmental protection equipment before discharged into the atmosphere.
1. Designing of Clinker Grinding Production Line
After gypsum, clinker and limestone are measured by the belt weigher, they will be mixed together in accordance with particular
proportions, and then sent to the stable weighing warehouse. During this process, magnetic metals are removed by the iron remover
from these materials. Then mixed materials will be sent into the rolling machine to be crushed. After crushed, they will be sent
to the powder separator, in which coarse powder will be sent back to the griding mill while the fine one will be sent to the
elevator for finished products. Finally, they will be sent to finished product storage. Meanwhile, dusty gas from the grinding
mill will be purified by the environmental protection equipment before discharged into the atmosphere.
2. Design of Slag Grinding Production Line
Gypsum, dry slag and pulverized coal are measured by the belt weigher before mixed together according to particular proportions.
Mixed materials will be sent to the mill for grinding, and during this process, iron remover is employed to remove magnetic metals
in these materials. After grinded, fine powder will be sent to high-efficeint powder separator, while coarse powder will be sent
back to the grinding mill. Finished cement will be collected by the air tank pulse bag filter, while the fine powder will be sent
to the storage for finished products through an elevator. Dusty gases from the mill will be used as the first gas to enter into
the powder concentrator, which is followed by fresh air. Finally, dusty gas will be purified by the air tank pulse bag filter
before discharged into the atmosphere.
3. Design of Mixing Fine Slag and Powder Clinker
Besides the fineness of powder clinker and fine slag in the grinding production line, accurate measuring and even mixing also need
to be paid much attention to. That's why we choose to use the screw measurer as the measuring device and the air slide as mixing
device as well as conveying device.
FAQ
Q: Why we believe in luoyang zhongtai industries co., ltd: A: 1. More than 30 years experience. 2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts. 3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates. Q:Delivery time A: parts lead time 1-2months, machines 2-3months. Q:Payment terms A: Accept payment type: T/T, L/C, Western union,Cash. 30% deposit when signed contract. Full payment paid before shipping Q: Quality warranty? A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply. Q: After sales service? A: we can supply technical guide for machines running test and parts maintenance if end user needs.
