5.0×74 6000TPD Cement Rotary Kiln For Dry Process Production Lines

Price Negotiable

Price: negotiable

MOQ: 1 set

Delivery Time: 30 days

Brand: ZTIC

Product Description

High Productivity cement rotary kiln for dry process production lines

Introduction

As the main equipment in both of the cement clinker dry and wet process production lines, this cement rotary kiln is widely used in metallurgy field, chemical industry, building refractory material sector, environmental protection field, and so on. It mainly consists of cylinder body, supporting device, supporting device with catch wheel, driving device, movable kiln head, sealing equipment of the kiln end, coal spraying pipe, etc

Technical Data

Model No.( m)			φ2.8/2.5×44	φ3×48	φ3.2×50	φ3.3×50	φ3.5×54	φ4×60	φ4.3×64	φ4.8×74	φ5.0×74
Capacity(t/d)			300	600-700	1000	1200	1500-1800	2500	3500	5000	6000
Kiln Shell Slope(%)			3.5	3.5	3.5	4	4	4	4	4	4
Supporters ( pcs)			3	3	3	3	3	3	3	3	3
Thrust Roller Type			Mechnical	Mechnical or	Hydraulic	Hydraulic	Hydraulic	Hydraulic	Hydraulic	Hydraulic	Hydraulic
				Hydraulic
Rotating Speed of the Kiln		Main	0.445-2.22	0.676-3.38	0.36-3.57	0.36-3.57	0.39-3.9	0.41-4.07	0.4-4.0	0.35-4	0.35-4
		Driving
		(r /min)
		Auxiliary	4.75	9.36	6.5	5.61	7.66	8.2	7.93	8.52	7.58
		Driving (r/min)
Main	Motor	Model	ZSN4-	Z2-101	ZSN4-	ZSN4-	ZSN4-	ZSN4-	ZSN4-	ZSN4-	ZSN4-
Driving			225-21		280	280-	315-	355-	355-	450-092	450-092
					-191B	191B	92	92	12	Lp44
		Power (Kw)	55	100	160	160	220	315	400	630	710
		Speed Range ( r/min)	~1000	~1500	1500	1500	1000	1000	100-1000	1500	87.5
											~1000
		Voltage (V)	440	220	440	440	440	440	440	660	600
	Reducer	Model	ZS145-1-1	ZS145-1-1	ZSY-450-	ZSY450	NZS995-	YNS1110-	YNS1400-	JH710C-	JH280C-
					40-V	-40	28VIBL	22.4VBR	3105VIBL	SW305-40	45
		Speed Ratio	49-63	50	40	40	28	22.4	31.5	42.226	28
Auxiliary Driving	Motor	Model	Y122M-4	Y160M-6	Y160M-4B	Y160M-4	Y200L1-6	Y180L-4	Y200L-4	Y225M-4 lp44	Y250M-4
		Power ( kw)	4	7.5	15	11	18.5	22	30	55	55
		Rotating	1440	970	1460	1460	970	1470	1470	1480	1480
		Speed (r/min)
		Voltage ( V)	380	380	380	380	380	380	380	380	380
	Reducer	Model	ZL35-16	ZL35-7-1	ZSY160-31.5-II	ZSY355-31.5	ZSY355	YNS440-45IIR	YNS497-45ZC	JH220C-	JH280C-45
										SW302-28
		Speed Ratio	40.44	14	31.5	31.5	45	45	45	28	45
Total Weight			177	213	280.6	317	341	434	562	854	885
( not including refractoy bricks) ( t)
