Copper Core PVC Insulation Sheath Parallel Joint Electric Wire Cable
3 Wire Electrical Cable Copper Core PVC Insulation Sheath
Parallel Joint Flexible Wire
Product Specification:
Keeping working temperature under 70 centifree for long-rang operation.
Application:
Widely used as connectors of driving, lighting, electric equipments , instrument and telecommunication equipments
General purpose indoor and outdoor, electrical tools, washing machines, and vacuum cleaners etc.
|
Model No.
|
300/300V
|
|||
|
line-core structure root number / mm, (mm)
|
Min. Dia. mm
|
Ma mm x.
|
Max. Resistance at 20°C MΩ/km
|
|
|
2×0.50
|
16/0.20
|
4.8
|
6
|
39
|
|
2×0.75
|
24/0.20
|
5.2
|
6.4
|
26
|
|
3×0.50
|
16/0.20
|
5
|
6.2
|
39
|
|
3×0.75
|
24/0.20
|
5.4
|
6.8
|
26
|
|
Model No.
|
300/500V rated voltage
|
|||
|
line-core structure root number / mm, (mm)
|
Min. Dia. mm
|
Ma mm x.
|
Max. Resistance at 20°C MΩ/km
|
|
|
2×0.75
|
24/0.20
|
6
|
7.6
|
26
|
|
2×1.0
|
32/0.2
|
6.4
|
8
|
19.5
|
|
2×1.5
|
30/0.25
|
7.4
|
9
|
13.3
|
|
2×2.5
|
49/0.25
|
8.9
|
11
|
7.98
|
|
3×0.75
|
24/0.20
|
6.4
|
8
|
26
|
|
3×1.0
|
32/0.20
|
6.8
|
8.4
|
19.5
|
|
3×1.5
|
30/0.25
|
8
|
9.8
|
13.3
|
|
3×2.5
|
49/0.25
|
9.6
|
12
|
7.98
|
|
4×0.75
|
24/0.20
|
6.8
|
8.6
|
26
|
|
4×1.0
|
32/0.20
|
7.6
|
9.4
|
19.5
|
|
4×1.5
|
30/0.25
|
9
|
11
|
13.3
|
|
4×2.5
|
49/0.25
|
10.5
|
13
|
7.98
|
|
5×0.75
|
24/0.20
|
7.4
|
9.6
|
26
|
|
5×1.0
|
32/0.20
|
8.3
|
10
|
19.5
|
|
5×1.5
|
30/0.25
|
10
|
12
|
13.3
|
|
5×2.5
|
49/0.25
|
11.5
|
14
|
7.98
|
Product Details:
Packaging And Shipping:
a) Packing lengths: 100m/roll, 200m/roll, 305m/roll or up to your requirments
b) Inner packing: wooden reel,coil, plastic reel
c) Outer packing: carton box
d) Other packing available according to customer
Packaging And Shipping:
Packaging Details:
Packaging can be customized as required
Port: Fuzhou
Shipping:Support Sea Freight/Air Freight
FAQ
Q: What payments can be accepted?
A: T/T in advance, D/P at sight, L/C at sight, Paypal are available.
Q: Do you accept small order?
A: Yes, sample order is available.
Q: How to ship the cargos?
A: We usually ship by Airline, courier, and by sea.
Q: What's your warranty policy?
A: Our warranty period is 12months. Usually, all our products will be tested 100% one by one before delivery.
Q: Are OEM & ODM available?
A: Yes, both are available.
Q: Can we have our logo to be printed on the units or package?
A: For bulk order, we can print logo, customize package as your demands.
Q: Can we have one sample order or small order to try?
A: Yes, welcome to order small quantity for test at first.
Q: How could I get samples?
A: We can provide samples to you via your courier freight collect account.
