Terbium Gallium Garnet TGG Crystal Stick For Optical Components
Price:
Negotiable
MOQ:
1
Delivery Time:
3-4 weeks
Brand:
Crystro
Product Description
Terbium Gallium Garnet TGG Crystal Stick For Optical Components
Production Parameter
Brief Introduction:
Terbium Gallium Garnet (TGG) is a kind of synthetic garnet, a kind of magneto-optical crystal with a high level of thermal conductivity for Faraday rotators and isolators. It can be used in optical isolators and rotators for laser systems and in optical circulators for fiber optic systems, optical modulators and current and magnetic field sensors.
| Main specifications | Physical and Chemical Properties | ||
| Directional accuracy | <111>within ±15 arc min | Chemical Formula | Tb3Ga5O12 |
| Wave front distortion | <λ/8 wave total | Lattice constants | a=12.355 |
| Extinction ratio | >30dB | Growth method | Czochralski method |
| Diameter | +0.00mm/-0.05mm | Density | 7.13g/cm3 |
| Length | +0.2mm/-0.2mm | Mohs hardness | 8 |
| Chamfer | 0.2mm at 45° | Melting point | 1725℃ |
| Flatness | <λ/10 wave at 633nm | Index of refraction | 1.954 at 1064nm |
| Parallelism | <30 arc seconds | Thermal conductivity | 7.4 W·m-1·K-1 |
| Verticality | <5 arc minutes | Size | According to your request |
| Surface quality | 10/5 Scratch/Dig | ||
| AR coating | <0.2% | ||
Main Features:
- Large Size Boule Diameter: up to 4”
- Extinction Ratio Typical: >35 dB High Grade: >40 dB
- Verdet Constant 40 rad/T/m at 1064 nm
- Refractive Index 1.95 at 1064 nm
Main Advantages:
1. Large Verdet Constant :35 Rad T-1m-1
2. Low Optical Losses : <0.1%/cm
3. High thermal conductivity : 7.4W m-1K-1
4. High laser damage threshold :>1GW/cm2
Certificates:
