Center Wavelength 780nm Free Space Optical Farady Isolators
Price:
Negotiable
MOQ:
1 PC
Delivery Time:
3-4 weeks
Brand:
Crystro
Product Description
Center wavelength 780nm Free-Space Optical Isolators Faraday Isolators
Free-Space Optical Isolators incorporate a Faraday Rotator and are specifically designed and manufactured to provide superior performance with high isolation, transmission, and power densities. Crystro's own magneto-optic crystal TGG, TSAG has the char of high extinction ratio, low absorption, low loss, etc. It is used in optical isolator to achieve reliable isolation and stable performance
Advantages :
- High isolation
- Low insertion loss
- High reliability and stability
- Extremely low polarization correlation loss and polarization dispersion
Specifications:
| Model No. | CI-5-780-HP |
| Center Wavelength | 780 nm |
| Operating Wavelength Range | ±10nm |
| Peak Transmission | >93% |
| Peak Isolation | ≥ 35dB |
| M2 Degradation | <10% |
| Clear Aperture | 5 mm |
| Optical Power(Average) | 20,50W or Specify |
| Damage Threshold | 10J/cm2@ 10ns |
| Storage Temperature Range | -20-70℃ |
| Tunable Temperature Range | 10-30℃ |
