Astra Tech EV® Dental Implant 3.0mm/ 3.6mm/ 4.2mm/ 4.8mm/ 5.4mm Premill Blank Abutment 14mm Engaging

Astra Tech EV® Dental Implant Internal Tiantium Premill Blank Abutment 14mm Engaging

Astra Tech EV®

*3.0mm/ 3.6mm/ 4.2mm/ 4.8mm/ 5.4mm

Material:
Ti 6AI-4V ELI (Supply from Germany)

Feature:

* Simply efficiency
* Precision machined up to ± 5µm
* Benefit from a faster and controlled turnaround time
* Different diameter available of 10mm, 14mm

Pre-milled Abutment Blanks, you can now produce titanium customised abutments with your milling equipment.
Boost your efficiency by using your milling machines and benefit from all major implant connections.

Approved by CE, ISO 9001, ISO 13485

* We also can provide another 3 type of premill as above picture shown. Welcome to further inquire. Thanks.

Points of Astra OsseoSpeed EV Dental Implant

OsseoSpeed™ EV S

All six diameters are offered in the habitual straight body geometry with apical cutting flutes. 3.6, 4.2 and 4.8mm diameter implants are provided in seven lengths of 6, 8, 9, 11, 13, 15 and 17mm while 3.0mm diameter implants are supplied in five lengths of 8, 9, 11, 13 and 15 mm while 5.4mm implants are furnished in six lengths of 6, 8, 9, 11, 13 and 15mm.

OsseoSpeed™ EV C

Conical top geometry implants are available in two diameters of 4.2 and 4.8mm. To facilitate the continuation of the implant diameter designation only the crestal aspect of the implant is as wide as the diameter designation. The actual implant body diameter is 0.6mm smaller than the given diameter designation. Both 4.2 and 4.8mm diameter implants are offered in six lengths of 8, 9, 11, 13, 15 and 17mm.

OsseoSpeed™ Profile EV

Profile EV implants are offered in both body styles, straight (PS) and conical (PC) top. Two diameters of 4.2 (yellow) and 4.8mm (blue) are produced and available in six lengths of 8, 9, 11, 13, 15 and 17mm. Profile implants require special impression copings and prosthetic components not compatible with regular EV type implants. Packaging for profile implants and prosthetics are marked with a capital "P" along with the color coding for easy identification.
