Kedel Carbide Foil Slitting Blade 100% Carbide 6 Months Warranty
Product Parameters
| NO. | OEM | Common Sizes (MM) |
|---|---|---|
| 1 | TCY | Φ30*Φ121.1 |
| 2 | FOSBER | Φ29Φ121.2 |
| 3 | Mitsubishi | Φ28Φ201.4 |
| 4 | Mitsubishi | Φ28Φ161 |
| 5 | K&M | Φ28Φ16.81.4 |
| 6 | Hsieh | Φ27Φ16.831.4 |
| 7 | Marquip | Φ26Φ16.831.2 |
| 8 | Isowa | Φ26Φ141.5 |
| 9 | Justu | Φ26Φ151 |
| 10 | Oranda | Φ265Φ121.4 |
| 11 | Oranda | Φ26Φ111.4 |
| 12 | Wanlian | Φ26Φ111.4 |
| 13 | Peters | Φ25Φ150.8 |
| 14 | Kaiuo | Φ25Φ131.3 |
| 15 | Jingshan | Φ25Φ10.51.3 |
| 16 | BHS | Φ24Φ21.2 |
| 17 | Agnati | Φ24Φ111 |
| 18 | FOSBER | Φ23Φ111.1 |
| 19 | Neide | Φ23Φ131.3 |
| 20 | Kaiuo | Φ23Φ101.3 |
| 21 | Justu | Φ21Φ121.3 |
| 22 | Justu | Φ20Φ12*1.3 |
| NOTE: Customization available per customer drawing or actual sample | ||
| Grade | WC | Ni | Ti | TaC | Density (g/cm³) | Hardness (HRA) | TRS (Mpa) | Porosity | Grain Size (μm) |
|---|---|---|---|---|---|---|---|---|---|
| KD115/YG6X | 93.5 | 6.0 | - | 0.5 | 14.90 | 93.00 | 2700.00 | A02/B00/C00 | 0.6-0.8 |
| KD335/YG10X | 89.0 | 10.5 | - | 0.5 | 14.40 | 91.80 | 3800.00 | A02/B00/C00 | 0.6-0.8 |
| KG6/YG6 | 94.0 | 6.0 | - | - | 14.90 | 90.50 | 2500.00 | A02/B00/C00 | 1.2-1.6 |
| KG8/YG8 | 92.0 | 8.0 | - | - | 14.75 | 90.00 | 3200.00 | A02/B00/C00 | 1.2-1.6 |
| KG9/YG9 | 91.0 | 9.0 | - | - | 14.60 | 89.00 | 3200.00 | A02/B00/C00 | 1.2-1.6 |
| KG9C/YG9C | 91.0 | 9.0 | - | - | 14.60 | 88.00 | 3200.00 | A02/B00/C00 | 1.6-2.4 |
| KG10/KG10 | 90.0 | 10.0 | - | - | 14.50 | 88.50 | 3200.00 | A02/B00/C00 | 1.2-1.6 |
| KG11/YG11 | 89.0 | 11.0 | - | - | 14.35 | 89.00 | 3200.00 | A02/B00/C00 | 1.2-1.6 |
| KG11C/YG11C | 89.0 | 11.0 | - | - | 14.40 | 87.50 | 3000.00 | A02/B00/C00 | 1.6-2.4 |
| KG13/YG13 | 87.0 | 13.0 | - | - | 14.20 | 88.70 | 3500.00 | A02/B00/C00 | 1.2-1.6 |
| KG13C/YG13C | 87.0 | 13.0 | - | - | 14.20 | 87.00 | 3500.00 | A02/B00/C00 | 1.6-2.4 |
| KG15/YG15 | 85.0 | 15.0 | - | - | 14.10 | 87.50 | 3500.00 | A02/B00/C00 | 1.2-1.6 |
| KG15C/YG15C | 85.0 | 15.0 | - | - | 14.00 | 86.50 | 3500.00 | A02/B00/C00 | 1.6-2.4 |
| KD118/YG8X | 91.5 | 8.5 | - | - | 14.50 | 93.60 | 3800.00 | A02/B00/C00 | 0.4-0.6 |
| KD338/YG12X | 88.0 | 12.0 | - | - | 14.10 | 92.80 | 4200.00 | A02/B00/C00 | 0.4-0.6 |
| KD25/P25 | 77.4 | 8.5 | 6.5 | 6.0 | 12.60 | 91.80 | 2200.00 | A02/B00/C00 | 1.0-1.6 |
| KD35/P35 | 69.2 | 10.5 | 5.2 | 13.8 | 12.70 | 91.10 | 2500.00 | A02/B00/C00 | 1.0-1.6 |
| KD10/M10 | 83.4 | 7.0 | 4.5 | 4.0 | 13.25 | 93.00 | 2000.00 | A02/B00/C00 | 0.8-1.2 |
| KD20/M20 | 79.0 | 8.0 | 7.4 | 3.8 | 12.33 | 92.10 | 2200.00 | A02/B00/C00 | 0.8-1.2 |
| No. | Size (mm) |
|---|---|
| 1 | Φ45*φ25*0.25 |
| 2 | Φ50*φ20*0.15/0.2/0.3/0.4/0.5 |
| 3 | Φ105*φ65*0.7 |
| 4 | Φ80*φ20*0.2/0.3/0.5/0.6/0.8 |
| 5 | Φ80*φ30*0.2/0.3/0.5/0.6/0.8 |
FAQ
Q: How to obtain an accurate quotation from Kedel Tools?
A: Please provide us with specific material requirements, precise dimensions, and drawings that include tolerances and quantities for different models. This will allow us to provide you with a more accurate quote.
Q: How does our company ensure the quality of its products?
A: We have inspection processes from raw material production, to finished product grinding, to cleaning and packaging. Each process also has sampling inspection. If the product in the previous process is not qualified, it will never enter the second process. Ensure the quality of the finished product.
Q: How long does a typical production cycle take?
A: For products that are often in stock, they can be shipped directly. For customized products, the specific judgment is based on the difficulty level of product processing. Normally, non-standard products require 20-25 days for production.
Q: What is our company’s payment method?
A: We accept wire transfers, L/C, ALIPAY, WEST UNION, PAYPAL, 100% payment is required for standard products before shipment, 50% for non-standard products before production, and 50% before shipment.
