Food Industry Brush Type 10um Jumbo Cartridge Filter
Food Industry Brush Type 10μM Jumbo Cartridge Housings and Filters
Uninterrupted water supply:
the amount of water in cleaning is very small, 5% of the output water of the filter, the washing time is 2 ~ 15 seconds, the whole system is uninterrupted water supply.
High filtering precision:
filtering precision up to 20 microns, a variety of precision mesh for you to choose.
Large filtration area:
the effective filtration area of standard filter screen is 7 ~ 40 times of the inlet area.
Reliable cleaning:
there are a variety of control methods, manual, differential pressure, time, PLC program logic control options.
Economical and simple installation:
various structural forms, suitable for all kinds of site installation, without affecting the operation effect.
| type | X01 -219 |
X01 -273 |
X01 -325 |
X01 -426 |
X01 -530 |
X01 -630 |
X01 -720 |
X01 -820 |
X01 -920 |
X01 -1020 |
| pipe diameter (mm) | 50 | 80 | 100 | 200 | 250 | 300 | 350 | 400 | 450 | 500 |
| To filter traffic (m3h) | 20 | 50 | 150 | 300 | 500 | 700 | 1100 | 1500 | 2000 | 2500 |
| filter area (m2) | 0.27 | 0.25 | 0.35 | 0.66 | 1.6 | 0.85 | 1.3 | 1.4 | 1.8 | 2.3 |
| blow-down valve (mm) | 25 | 25 | 25 | 50 | 50 | 80 | 80 | 80 | 80 | 80 |
| Primary cleaning water quantity(L) | 80 | 80 | 80 | 150 | 150 | 350 | 450 | 600 | 800 | 1000 |
| motor power (KW) | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
| type | D(mm) | H(mm) | H1(mm) | H2(mm) | L1(mm) | L2(mm) |
| X01-219 | 219 | 450 | 830 | 1130 | / | 190 |
| X01-273 | 273 | 500 | 885 | 1185 | / | 217 |
| X01-325 | 325 | 500 | 945 | 1170 | / | 283 |
| X01-426 | 426 | 500 | 1130 | 1350 | 325 | 343 |
| X01-530 | 530 | 650 | 1330 | 1550 | 370 | 415 |
| X01-630 | 630 | 685 | 1360 | 1660 | 400 | 460 |
| X01-720 | 720 | 700 | 1500 | 1730 | 400 | 510 |
| X01-820 | 820 | 765 | 1600 | 1870 | 450 | 600 |
| X01-920 | 920 | 900 | 1720 | 1980 | 450 | 660 |
| X01-1020 | 1020 | 920 | 1850 | 2100 | 500 | 710 |
Working principle of self-cleaning filter:
When the pressure difference between the inlet and outlet of the filter reaches the preset value, the filter will start the self-cleaning process. The whole self-cleaning process consists of two steps: opening the blowdown valve on the upper end cover of the filter;The motor drives the two stainless steel brushes inside the filter to rotate, so the impurities caught by the filter are brushed down by the steel brush and discharged from the blowdown valve.The entire cleaning process takes about 15-60 seconds, and the system does not stop the flow during the cleaning. The entire operation process of the filter is controlled by a control box equipped randomly.
Long service life:
normal life of more than 10 years, the filter for stainless steel, according to the need, can be very convenient to replace the different specifications of the filter.
self-cleaning Filter material:
Filter body: carbon steel, epoxy resin coating can be used stainless steel 316, 304 as required
Filter screen: stainless steel 316L wedge filter element;Stainless steel 316L woven wire
Cleaning mechanism (internal) : stainless steel 304,316L, POM
Blow-off valve: cast iron, epoxy resin coating;304316 L
Sealing ring: synthetic rubber, polytetrafluoroethylene
