500kg 1.6M Manual Scissor Reach Stacker CQY-0.5T
500kg 1.6M Manual Scissor Reach Stacker CQY-0.5T
Size Information
| Item | Model |
CQY-0.5T |
|
| 1 | Load Capacity | kg | 500 |
| 2 | Lifting height | mm | 1600 |
| 3 | Load center | mm | 500 |
| 4 | Lifting speed | mm/s | 45 |
| 5 | Forward shift | mm | 0-350 |
| 6 | Lowering speed | Controllable | |
| 7 | Overall dimensions | mm | 1600*650*1960 |
| 8 | Fork length | mm | 800 |
| 9 | Fork adjustment width | mm | 160-480 |
| 10 | Min. Ground clearance | mm | 85 |
| 11 | Turning radius | mm | 1200 |
| 12 | Front wheel size | mm | 125*50 |
| 13 | Rear wheel size | mm | 80*50 |
| 14 | Self weight | kg | 150 |
Description
The forward-moving stacker is a type of stacker, which has been widely used in warehouse stacking and handling and loading and unloading. The basic aspect of the forward-moving stacker is similar to that of the counterweight type. There is no counterweight on the front bottom legs. Appropriately shorten the length of the stacker, which can alleviate the passage requirements to a certain extent.
Advantages
1. The fork of the gantry can be retracted forward and backward, which is convenient and quick to pick up the goods.
2. The length of the whole vehicle is variable, and the turning radius is small, which is more conducive to turning in narrow passages.
3. The distance between the two forks can be adjusted at will. The forks are generally forged forks, with a small thickness, which is convenient for picking up various pallets and goods.
4. The wheels are large and the chassis is high, which is convenient for passing through various complex work sites and has good climbing ability.
5. High work efficiency.
Product details
Production Scene
Packing &Shoping
FAQ
Q1: Can Herrman provide customized products? OEM products or ODM products?
A1: Yes, Herrman can provide customized products according to your requirement. Both OEM and ODM are acceptable. We do a lot ofnon-standard products, welcome your special custom-made.
Q2: What's the specification of the chargers?
A2: Herrman have all kinds of the chargers and welcome the customers to custom-made.
Q3: How about the delivery time?
A3: Usually Herrman producing time is 15-20 working days after we receive the advanced payment. For some standard products, we have most in stock and could delivery immediately.
Q4: Can we print the LOGO on products?
A4: Yes, the OEM is available with the permission of our customers.
Q5: What is your payment term?
A5: T/T,L/C or O/A if you want any other way, please contact us.
Q6: What can I get from cooperating with Herrman?
A6: 1. Unique products, with customized service.
2. Timely production and delivery, time is money.
3. Market protection service, long term business strategy.
