12V 150Ah 1920Wh Lithium Lifepo4 Battery For Leisure Marine Vehicles With LCD Display
Price:
430-450USD/PC
MOQ:
1
Delivery Time:
10-30days
Brand:
MaxLi
Product Description
MaxLi 12V 150Ah smart lithium lifepo4 battery with LCD display for leisure/marine vehicles:
|
Electrical Characteristics |
Nominal Voltage | 12.8V |
| Nominal Capacity | 150Ah | |
| Energy | 1920Wh | |
| Internal Resistance | ≤ 20mΩ | |
| Cycle Life | ＞3000cycles @1.0C 100%DOD | |
| Months Self Discharge | ＜3% | |
| Efficiency of Charge | 100%@0.2C | |
| Efficiency of Discharge | 96~99%@0.5C | |
|
Standard Charge |
Charge Voltage | 14.6±0. 1V |
| Charge Mode | 0.2C to 14.6V,then 14.6V,charge current to 0.02C(CC/CV) | |
| Charge Current | 100A | |
| Max. Charge Current | 150A | |
| Charge Cut-off Voltage | 14.6V±0. 1V | |
|
Standard Discharge |
Continuous Current | 150A |
| Max. Pulse Current | 450A(<5S) | |
| Discharge Cut-off Voltage | 10.8V | |
|
Environmental |
Charge Temperature | 0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
| Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |
| Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity | |
| Water Dust Resistance | IP65 | |
|
Mechanical |
Cell & Method | Top A grade new prismatic cells |
| Shell material | ABS | |
| Dimensions (in./mm.) | 355x175x190mm | |
| Weight (lbs./kg.) | Approx:17.0Kg | |
| Terminal | M8 | |
| Communication | LCD display/Bluetooth is available |
Applications:widely used on RV/Caravans/Camperings/Marine vehicles ect:
Well package with high quality UN standard carton and foam:
Strictly according to CE/UN38.3/MSDS/ROHS to reach the high quality battery:
