Portable Bluetooth App 200Ah 12V Lithium Battery Pack IP56 ABS Case

Price Negotiable
Price: $470-$500/PCS
MOQ: 20
Delivery Time: 15 days for samples and 30 days for bulk order
Brand: MaxLi
Product Description

Portable Bluetooth App 200Ah 12V Lithium Battery Pack IP56 ABS Case



New Bluetooth App 200Ah 12V Lithium battery pack



MaxLi-12V 200AH lIFEPO4 BATTERY PACK-BLUETOOTH FUNCTION



1.Specification



Model No.

YS-12-200-BT

Weight (Kg)

26KG

Length (mm)

523

Width (mm)

235

Height (mm)

222

Voltage (V)

12.8V

Capacity (Ah)

200Ah

Terminal Type

M8

Communication

Bluetooth (support Android and apple smart phone)

Life expectancy

3000 Cycles 100% DOD

Recommend Charge Current

0.2-0.5C

Charge mode

0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV)

Months Self Discharge

Less than 3%

Enclosure Protection

IP56





New APP function:



1. Can display or hide single cell voltage



2. Users can monitor battery informations via App



3. The battery can be activated via Bluetooth



4. Will have an alarm if the battery is abnormal



5. OEM service is available.



6. App is available in both app stores(Android and Iphone)



2. Standard Test Conditions



Test should be conducted with new batteries within one week after shipment from our factory and the batteries shall not be cycled more than five

times before the test. Unless otherwise specified, test and measurement shall be done under temperature of 20±5℃ and relative humidity of

45~85%. If it is judged that the test results are not affected by such conditions, the tests may be conducted at temperature 15~30℃ and humidity

25~85%RH.



3. Storage & Transportation



  • Based on the character of cell, proper environment for transportation of LiFePO4 battery pack need to be created to protect the battery.

  • Battery should be stayed in the ware house -20℃~35℃ where it’s dry, clean, shade, and well-ventilated.

  • The battery should be stored in 50% SOC during transportation.

  • The battery need to be charged every 6 months if out of use.

  • Keep the battery against dropping, turning over and serious stacking during loading.



3. Application



Energy Storage:Solar-Wind Power System / City Grid (On/Off) / Community and Family / RV Motorhome /Golf Carts Battery / Boat Marine Yachts



Back-up System and UPS:Telcom Base / CATV system / Computer Server Center / Military Equipment.



Other Applications:Security and Electronics /  LED Light / Emergency Light / LED Backup / Engine Starting Battery,etc.



5.Why Choose MaxLi LiFePO4 Battery Pack?

1. All MaxLi lithium batteries are made of LiFePO4 Grade A cells, which are the most stable and safe lithium cell.



2. Our battery pack use imported IC & MOS ( ST, RT chip) , pure coppe, Pure copper nickel-plated terminals, 304stainless steel screw and etc.



3. All batteries will be full inspection 100% before shpping, provide 3/5 years warranty



4. We provide MSDS/UN38.3/CE or other certifications for shipping



5. MaxLi have professional development and resarch team on pack technology, espcially in Bluetooth, heating system, RS232/RS485/CAN.





6. Package of Battery Pack
