MaxLi LiFePO4 Battery 12V 100Ah Smart Lithium Battery For RV/Caravan/Campering Built-In Bluetooth
MaxLi smart lithium battery with built-in bluetooth for RV/Marine automative vehicles
|
Electrical Characteristics |
Nominal Voltage | 12.8V |
| Nominal Capacity | 100Ah(102Ah) | |
| Energy | 1280Wh | |
| Internal Resistance | ≤ 20mΩ | |
| Cycle Life | ＞3000cycles @1.0C 100%DOD | |
| Months Self Discharge | ＜3% | |
| Efficiency of Charge | 100%@0.2C | |
| Efficiency of Discharge | 96~99%@0.5C | |
|
Standard Charge |
Charge Voltage | 14.4±0. 1V |
| Charge Mode | 0.2C to 14.4V,then 14.4V,charge current to 0.02C(CC/CV) | |
| Charge Current | 50A | |
| Max. Charge Current | 100A(150A BMS is available) | |
| Charge Cut-off Voltage | 14.6V±0. 1V | |
|
Standard Discharge |
Continuous Current | 100A |
| Max. Pulse Current | 300A(<3S)/ 450A(<3s) | |
| Discharge Cut-off Voltage | 10.0V | |
|
Environmental |
Charge Temperature | -20 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity |
| Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |
| Storage Temperature | 0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity | |
| Water Dust Resistance | IP65 | |
|
Mechanical |
Cell & Method | 32700 6 Ah 4S17P |
| Shell material | ABS (group24/31 DIN5) | |
| Dimensions (in./mm.) | 330*173*214mm/260*168*210mm/353*180*190mm | |
| Weight (lbs./kg.) | Approx:12Kg | |
| Terminal | M8 | |
| Communication | Bluetooth is optional |
More details of 12V 100Ah smart lithium battery:
Certified with CE/RoHS/UN38.3/MSDS certificates to reach the high quality standard:
Details of MaxLi battery factory:
MaxLi is a full qualified manufacturer of high quality lithium battery under a wide range of specs.
A wholly-own more than 6000㎡ factory is located in Dongguan city with multi professional production lines and experienced R&D team.
OEM/ODM service is available with confidential agreements.
Feel free to contact Zina for more details.
