Bidirectional 400um 1200mm BOPP Film Production Line
Bidirectional& simultaneous stretching film production line is used to produce spccial films like LI-lon battery separate film,optical film,and shrink film etc.
Product Description
Preheating, drawing and heat setting rolls:
The heat in the roller is transferred to the film through the outer layer of the roller. In order to make the roller surface temperature uniform, hot water flows around the roller surface along the film area of the spiral channel. The inner and outer surfaces of the roller need to be machined to ensure uniform wall thickness of all parts of the roller. Through special calculation, the type and clearance of the runner in the roller ensure the uniform distribution of hot water in each channel and the uniform surface temperature of the roller. The roller bearing adopts imported high-temperature and high-precision self-aligning roller bearing. The rotating side is fixed and the operating side is swimming thermal elongation.
Technical Data
| Casting film Thickness | 400~3200um |
| Finished film thickness | 50～300um |
| Casting film width | 1450mm |
| Finished film width | 4700mm |
| MD ratio | 1:1—1:4 |
| TD ratio | 1:2—1: 5 |
| Production speed | max140m / min |
| Main Extruder output | |
| Sub Extruder output | max 1000 kg/h |
| Winding diameter | max φ1200 mm |
Major Function
. Bidirectional & simultaneous stretching
. PLC central control
. Longitudinal-stretching free
. Adjustable ratio of bidirectional stretching
. Auto rewinding
Packaging & Delivery
1. Prompt delivery;
2. Professional logistic agent;
3. Well-trained and disciplined packing team;
4. After-sale service: Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
Competitive Advantages
1. We offer high quality products at competitive price;
2. customs clearance is guaranteed;
3. Good after-sale service;
4. Flexible payment terms;
5. With excellent products and efficient services, we are well known both at home and abroad.
Our Factory
Our customers
FAQ
Q: How about the warranty and after-sale service?
A: We provide 12 months warranty and lifetime technic suport for all machinery.
The response is available within 12 hours while the solution for the troubleshooting is provided within 48 hours.
Q. Machine installation
A. We could assign the technician to the place for the on-site installation if requested by the purchaser.
