15KHz 4200W Ultrasonic Plastic Welding Machine For Plastic Welding PTS2000 Series

Description:

As the backbone of the ultrasonic welding machine products, this series of products integrate a variety of precision control techniques, including welding machine balancing system/horizontal adjustment system, linear slide rail lifting system, micrometer positioning system, mechanical pressure sensors, to meet the requirements of the complex welding work environment and diverse needs of customers.

At the same time, this series of full-system standards are equipped with a new generation of digital ultrasonic generators, 7-inch outside touch screens, electronic lifting systems, to achieve a higher cost performance.

Product Name	Ultrasound Plastic Welder PTS2000
Voltage	AC 220V 50/60HZ
Dimensions (WxHxD) [mm]	700*880*2000
Weight [kg]	280KG
Operating frequencies* [kHz]	15KHZ
Welding head operating stroke [mm]	100mm
Air pressure rate[MPa]	0.2-0.7MPa
Power [W]	4200W
Processor	4-core, 32-bit processor
Time Mode	0.001-9.999 Seconds
Welding amplitude	10%-100% adjustable(1% accuracy)
Welding mode	Time, Energy, grounding
Energy Mode	Integrated
Temperature	-10ºC--40ºC



Different models are available:



Frequency	Power	Work Stroke	Lifting Mode	Voltage	Air Source
15kHz	2600W	75MM	electric control	220V±10%	2kgf-8kgf
15khz	3200W	75MM
15khz	4200W	100MM
20kHz	2500w	75MM
20kHz	3000w	75MM
30KHz	1200W	75MM
35KHz	1200W	75MM
40KHz	800W	75MM
Operation interface:7 inches touch screen



Features:



1.  The ultrasound welder has three welding modes: time, energy, grounding;

2.  With two trigger Modes: delay, pressure;

3.  Three Amplitude managements: staged amplitude, adjusted amplitude, compensated amplitude;

4.  Quality management: time, energy;

5.  Safety managements: power overload protection, supply voltage protection, transducer voltage protection;

6.  This ultrasonic plastic welding machine is stable with high performance.



Application:



Electronic industry	The gum case of watch, nylon watch band, calculator, sound box wraps hull, cell phone battery etc.
Toy industry	Such as toy gun, water gun, telephone and rag baby etc.
Automotive industry	Car light, automotive interior parts etc.
Packing industry	Disguise box, PVC packing box, toothpaste tube etc.
General business ware	The inkjet cartridge, video cassette rack, tape box, computer disk etc.
Medical industry	Widely used in the medical industry due to the fast,clean,efficient of ultrasonic welding machine.



For more details about our ultrasonic plastic welders, welcome to click the catalog below:



Catalog of Ultrasonic Welding Press.pdf





Detailed Photos:





Warehouse:

Packing:
