SHANZHONG 21ton Wheel Excavator SZL215 Hydraulic Digger
Price:
USD98000/unit
MOQ:
1 unit
Delivery Time:
30days
Brand:
shanzhong
Product Description
21ton wheel Excavator SZL215 hydraulic Digger
Imported axles, imported hydraulic system, intelligent control, workmanship, high working efficiency, Fuel efficient
The overall performance of the hydraulic system is reasonably matched with the output power of the engine,which greatly reduces energy loss.
Intelligent control,four-wheel drive, four-wheel hydraulic oil brake
Cummins EFI engine turbocharging and fuel cooling system, high fuel efficiency, low fuel consumption,strong durability.
| Item | Size |
| Shipping Length | 9700m |
| Shipping Height | 3340mm |
| Overall Width | 2730mm |
| Radius,Swing Center to Rear End | 2750mm |
| Wheelbase | 2840mm |
| Wheel Tread | 1980mm |
| Counterweight Ground Clearance | 345mm |
| Min Ground Clearance | 1259mm |
| Ground Clearance of Outrigger | 450mm |
| Ground Clearance of Transmission | 420mm |
| Width of Bulldozer Plate | 2600mm |
| Height of Bulldozer Plate | 560mm |
| Lifting Height of Bulldozer Plate | 420mm |
| Bucket Volume | 1.0m³ |
| Boom Length | 5650mm |
| Arm Length | 2920mm |
| Max.Digging Radius | 9700mm |
| Max.Digging Height | 10600mm |
| Max.Digging Depth | 6350mm |
| Max.Dumping Height | 7800mm |
| Hydraulic System Pressure | 34.3Mpa |
| Hydraulic System Flow | 2*231.7 l/min |
| Bucket Digging Force | 134/126kn |
| Arm Digging Force | 99/93kn |
| Rotation Speed | 12r/min |
| Travel Speed | 28-40km/h |
| Gradeability | 35% |
| Approximate Weight | 21000kg |
