12V 50Ah - 300Ah Lead Acid Replacement LiFePO4 Batteries High Energy Density
12V 50Ah - 300Ah Lead Acid Replacement LiFePO4 Batteries
Lead to lithium battery, that is, the original use of lead-acid battery equipment (such as electric vehicles, motorcycles, energy storage systems, etc.) in the process of replacing the battery with lithium battery. The use of lead to lithium batteries can reduce the overall operating costs of equipment and improve energy efficiency.
Product features:
1. High energy density, smaller size, easier to use
2. Strong durability, long service life, charge and discharge cycles more than 4000 times
3. Good charging and discharging performance, support fast charging of equipment
4. Operating temperature -20-60°C ,Strong adaptability to high and low temperatures
5. Using self-developed battery and BMS, high safety performance
High performance parameter
| Model | HX-LTL-12.8/50 | HX-LTL-12.8/100 | HX-LTL-12.8/150 | HX-LTL-12.8/200 | HX-LTL-12.8/300 |
| Parameter | 12.8V50Ah | 12.8V100Ah | 12.8V150Ah | 12.8V200Ah | 12.8V300Ah |
| Cell Technology | LFP(LifePO4) | LFP(LifePO4) | LFP(LifePO4) | LFP(LifePO4) | LFP(LifePO4) |
| Cell Type | Prismatic Cell | Prismatic Cell | Prismatic Cell | Prismatic Cell | Prismatic Cell |
| Configuration | 4S1P | 4S1P | 4S1P | 4S2P | 4S1P |
| Rated Voltage | 12.8V | 12.8V | 12.8V | 12.8V | 12.8V |
| Rated Capacity | 50Ah | 100Ah | 150Ah | 200Ah | 300Ah |
| Energy | 640Wh | 1280Wh | 1920Wh | 2560Wh | 3840Wh |
| Max. Continuous Operating Current | 50Ah | 100Ah | 150Ah | 200Ah | 300Ah |
| Max. Peak Current(30s) | 100A | 200A | 300A | 400A | 400A |
| Operating Temperature | -20～60°C (-4～140°F) | -20～60°C (-4～140°F) | -20～60°C (-4～140°F) | -20～60°C (-4～140°F) | -20～60°C (-4～140°F) |
| IP Rating | IP67 | IP67 | IP67 | IP67 | IP67 |
| Dimension (W*D*H) |
229x138x208mm (12x6.6x8.2 inch) |
307x168x208mm (12x6.6x8.2 inch) |
483x170x240mm (12x6.6x8.2 inch) |
532x207x215mm (19x6.7x9.5 inch) |
522x240x218mm (20.9x8.1x8.5 inch) |
| Weight | 6.6kg | 10.5kg | 15kg | 19.6kg | 26.6kg |
| Casing | ABS | ABS | ABS | ABS | ABS |
| Cycle Life | 4000times | 4000times | 4000times | 4000times | 4000times |
| Certificates | CE/UE38.3 | CE/UN38.3 | CE/UN38.3 | CE/UN38.3 | CE/UN38.3 |
Application scenario
Lead to lithium batteries are widely used in RV, electric toy car, lawn mower, fish finder, battery car, ship, outdoor power supply and so on.
