SSA 580A Toshiba System Repair , clinic RX board maintenance
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
2-4 working days
Brand:
Toshiba
Product Description
Toshiba SSA-580A Maintenance
The machine starts normally, but there is no echo when it enters the ultrasonic working interface.
Fault analysis
Ultrasound image echo-free is a typical fault that all major brands of ultrasound machines will encounter. Usually, the reason for the failure is that the front-end plate of the power supply of the machine has no high-voltage output or is responsible for the processing function of ultrasound imaging. It is preliminary judged that there may be faults in the A43 FETX board and the A60 ETXR2 board, among which the A43 FETX board is the transmitting and receiving board and the A60 ETXR2 board is responsible for the tube of the high-voltage board. High voltage output of the probe.
Fault summary
After replacing the A60 ETXR2 board, the machine starts up normally. After entering the ultrasonic working interface, the image echo area is restored and the machine runs normally.
Ultrasound parts that we can repair:
| Repair List of Featured Ultrasonic Board & Assy | |||
| Brand | System | Description | Part Number |
| GE | Logiq P5 | CPU mainboard | 5168431 |
| GE | Logiq P6 | CPU mainboard | |
| GE | Logiq E9/vivid E9 | GFI2 | 5161631 |
| GE | Voluson E6/Voluson E8 | RSR | KTI301394-2/KTI196357 |
| GE | Voluson E6/Voluson E8 | RFI/ RFI21b Board | KTI300614/KTI302197-6 |
| GE | Voluson S6/S8/P8 | BF64 | 5396937-2 |
| GE | Voluson S6/S8/P8 | RFS board | 5364098-2/5364098-3 |
| GE | Voluson S6/S10/P8 | BF192 board | 5357234 |
| Aloka | Alpha 5 | mainboard | EP493700DD |
| Aloka | Alpha 6 | RX Beam Former | EP555501AA |
| Aloka | Alpha 6 | CW board | EP555700 |
| Aloka | Alpha 6 | CPU mainboard | EP537000/EP563000 |
| Aloka | Alpha 6 | TX/RX | EP555300 |
| Aloka | Alpha 6/Alpha 7 | DOM | EP550000AA |
| Aloka | Alpha 10 | RX Beamformer board | EP531800CE |
| Aloka | Alpha 10 | wave generator Board | EP495000HH/EP495000HJ/EP495000FF |
| Hitachi | F37 | TX/RS | EP557400/EP557300 |
| Hitachi | F37 | mainboard | EP575700BC/EP560800 |
| Aloka | F75 | USP board | EP556600 |
| Aloka | F75 | Cell Board | EP558800 |
| Hitachi | HI VISION Avius | RDBF board | 7513907A/7513612 |
| Hitachi | Arietta 60 | CELL | EU-9160C |
| Hitachi | Arietta 70 | TX | EP572300AA |
| Hitachi | Arietta 70 | CELL | |
| Hitachi | Noblus | CELL | |
| Hitachi | Noblus | CONT-B | |
| Hitachi | Ascendus | CELL | 7352830A |
| Siemens | X150/G40 | BE | 10131804 |
| Siemens | X300 | BE 2.0/BE 3.0/BE 7.5 | 10131990 |
| Siemens | X700 | BE | 10136465 |
| Siemens | X700 | RC | 10136467 |
| Siemens | X700 | TI | 11014292 |
| Siemens | Antares | BE | 7472421 |
| Siemens | Antares | CB | 7288504 |
| Siemens | S2000 | RM300 | 10852163 |
| Siemens | S2000 high version/S3000 | RM301 | 10854749 |
| iU22/iE33 | EMB excelsior motherboard | 453561419431/453561382231/453561419431 | |
| iU22/iE33 | UMB Unified Motherboard | 453561254492/453561360251 | |
| HD15 | ACB acquisition control board | 453561197145/453561197144 | |
| HD15 | AIM board | 4.53561E+11 | |
| CX50 | control panel | 4.53562E+11 | |
| CX50 | mainboard | 453561368033/453561622163/453561495832 | |
| Affiniti 70 | ACQ acquisition control board | ||
| EPIQ 5/EPIQ 7 | ACQ Acquisition Module board | 453561734844/453561704246 | |
| Esaote | Mylab Series | CPU mainboard | 9501361000 |
| Toshiba | Aplio 300/400/500 | mainboard | PM30-38696 |
| Toshiba | Aplio 500 | RX | ywm2056*a |
| Toshiba | Xario 200 | TX | PM30-32732-1 |
| Toshiba | Xario 200 | RX | PM30-32733-1 |
| Remarks | |||
| 1.The repair cycle is within 3-5 days. | |||
| 2.Warranty after fixed:60 days. | |||
| 3. Kindly send us the estimated main faults (better to have image) for our engineer to prejudge. | |||
| 4.Package price is available if repair 3 pcs or more at one time. | |||
| 5.Extra discount for VIP partners. | |||
| 6.You could have different part No.under same description. | |||
Basic components of color Doppler ultrasound
1. Monitor (CRT/LCD)
2. Control panel (Touch screen, Numeric keyboard)
3. Front end (Probe interface board, FEC, AIM, CB)
4. Back end (Graphics card, DSC, Uavio, Mainboard )
5. Power supply(AC,PSA)
6. CD driver
7. Probe
