ALOKA Alpha 5 Ultrasound Machine Repair Color Doppler
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
2-4 working days
Brand:
Hitachi
Product Description
ALOKA Alpha 5 color doppler ultrasound fault repair case
ALOKA alpha 5 is equipped with advanced front-end technology, original data processing platform,high-capacity digital beam generator (12bit digital beam generator) and other technologies to ensure the high-quality image of all organs in the body.And as well as the varties probes in ALOKA, ALOKA alpha 5 can meet the needs of linical diagnosis and scientific research,At present, ALOKA alpha 5 is used in many hospitals in China. Now we will analyze one of the common faults encountered in the use of ALOKA alpha5.
Faults phenomenon
When operating the CW(continuous doppler), the diagnostic instrument crashed with an error prompt, and the other functions were all normal.Error warning: the machine detects abnormal voltage, please restart the system.
Failure analysis
(1)The CW function of the diagnostic instrument can only be used in cardiac, and it has no such function in other conditions, so the CW board may be damaged.
(2) in case the appearance of the fault, the working voltage of CW measured by the attached power box drops significantly, which may be caused by the attached power box.
(3) this fault may also be caused by CW signal and loss of communication function.
(4) the heart probe (phased array probe) is composed of PW and CW, and the heart probe may be damaged.
(5) the software system is damaged, resulting in the loss of CW function.
Troubleshooting
It’s not working after replacing the attached power box and related circuit boards,the dead phenomenon didn’t appeared when the heart probe was replaced . The problem was e circuits of the machine appeared,the restart of the machine are required.
Ultrasound parts that we can repair:
| Repair List of Featured Ultrasonic Board & Assy | |||
| Brand | System | Description | Part Number |
| GE | Logiq P5 | CPU mainboard | 5168431 |
| GE | Logiq P6 | CPU mainboard | |
| GE | Logiq E9/vivid E9 | GFI2 | 5161631 |
| GE | Voluson E6/Voluson E8 | RSR | KTI301394-2/KTI196357 |
| GE | Voluson E6/Voluson E8 | RFI/ RFI21b Board | KTI300614/KTI302197-6 |
| GE | Voluson S6/S8/P8 | BF64 | 5396937-2 |
| GE | Voluson S6/S8/P8 | RFS board | 5364098-2/5364098-3 |
| GE | Voluson S6/S10/P8 | BF192 board | 5357234 |
| Aloka | Alpha 5 | mainboard | EP493700DD |
| Aloka | Alpha 6 | RX Beam Former | EP555501AA |
| Aloka | Alpha 6 | CW board | EP555700 |
| Aloka | Alpha 6 | CPU mainboard | EP537000/EP563000 |
| Aloka | Alpha 6 | TX/RX | EP555300 |
| Aloka | Alpha 6/Alpha 7 | DOM | EP550000AA |
| Aloka | Alpha 10 | RX Beamformer board | EP531800CE |
| Aloka | Alpha 10 | wave generator Board | EP495000HH/EP495000HJ/EP495000FF |
| Hitachi | F37 | TX/RS | EP557400/EP557300 |
| Hitachi | F37 | mainboard | EP575700BC/EP560800 |
| Aloka | F75 | USP board | EP556600 |
| Aloka | F75 | Cell Board | EP558800 |
| Hitachi | HI VISION Avius | RDBF board | 7513907A/7513612 |
| Hitachi | Arietta 60 | CELL | EU-9160C |
| Hitachi | Arietta 70 | TX | EP572300AA |
| Hitachi | Arietta 70 | CELL | |
| Hitachi | Noblus | CELL | |
| Hitachi | Noblus | CONT-B | |
| Hitachi | Ascendus | CELL | 7352830A |
| Siemens | X150/G40 | BE | 10131804 |
| Siemens | X300 | BE 2.0/BE 3.0/BE 7.5 | 10131990 |
| Siemens | X700 | BE | 10136465 |
| Siemens | X700 | RC | 10136467 |
| Siemens | X700 | TI | 11014292 |
| Siemens | Antares | BE | 7472421 |
| Siemens | Antares | CB | 7288504 |
| Siemens | S2000 | RM300 | 10852163 |
| Siemens | S2000 high version/S3000 | RM301 | 10854749 |
| Philips | iU22/iE33 | EMB excelsior motherboard | 453561419431/453561382231/453561419431 |
| Philips | iU22/iE33 | UMB Unified Motherboard | 453561254492/453561360251 |
| Philips | HD15 | ACB acquisition control board | 453561197145/453561197144 |
| Philips | HD15 | AIM board | 4.53561E+11 |
| Philips | CX50 | control panel | 4.53562E+11 |
| Philips | CX50 | mainboard | 453561368033/453561622163/453561495832 |
| Philips | Affiniti 70 | ACQ acquisition control board | |
| Philips | EPIQ 5/EPIQ 7 | ACQ Acquisition Module board | 453561734844/453561704246 |
| Esaote | Mylab Series | CPU mainboard | 9501361000 |
| Toshiba | Aplio 300/400/500 | mainboard | PM30-38696 |
| Toshiba | Aplio 500 | RX | ywm2056*a |
| Toshiba | Xario 200 | TX | PM30-32732-1 |
| Toshiba | Xario 200 | RX | PM30-32733-1 |
| Remarks | |||
| 1.The repair cycle is within 3-5 days. | |||
| 2.Warranty after fixed:60 days. | |||
| 3. Kindly send us the estimated main faults (better to have image) for our engineer to prejudge. | |||
| 4.Package price is available if repair 3 pcs or more at one time. | |||
| 5.Extra discount for VIP partners. | |||
| 6.You could have different part No.under same description. | |||
