Single Mode GYFTY 48 Core Submersible Fiber Optic Cable
Price:
Negotiation
MOQ:
1KM
Delivery Time:
30 working days after received your payment
Brand:
Yiyuan
Product Description
Single Mode GYFTY 48 Core Submersible Fiber Optic Cable
Product Description
| No. of fiber | 4F | 12F | 24F | 36F | 48F | 72F | 96F | 144F |
| No. of tube(Customized) | 1 | 2 | 4 | 3 | 4 | 6 | 8 | 12 |
| Fiber per tube(Customized) | 6 | 6 | 6 | 12 | 12 | 12 | 12 | 12 |
| No. of filler rod | 4 | 3 | 1 | 2 | 1 | 0 | 0 | 0 |
| Nom. out diameter (±0.2mm) | 7.8 | 7.8 | 8.0 | 9.5 | 10.0 | 11.5 | 12.5 | 13.5 |
| Nom. jacket thickness (±0.1mm) |
1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.6 | 1.7 | 1.7 |
| Loose tube | Material | PBT | Color | Standard spectrum | ||||
| Filler rod | Material | PP | Color | Black | ||||
| Tube filling | Material | Filling compound | ||||||
| Central strength member | Material | FRP | Diameter | 1.4mm (6-48F) | ||||
| 2mm (72-144F) | ||||||||
| Layer | PE (for 96F -144F only) | |||||||
| Water blcoking system | Material | water blocking tape | ||||||
| Out sheath | Material | MDPE | Color | Black/customize | ||||
Features
* Good mechanical and temperature performance.
* High strength loose tube that is hydrolysis resistant.
* Special tube filling compound ensure a critical protection of fiber.
* Crush resistance and flexibility.
* The following measures are taken to ensure the cable watertight.
* Single Fiber Reinforced Plastic as the central strength member.
* 100% Loose tube filling compound.
* 100% cable core filling.
Applications
Long distance and local area network(LAN) communication.
Aerial & conduit/duct application.
