795kg/Km Subsea Fiber Optic Heavy Duty Armoured Cable GYTA5333 4-144 Core Single Mode
Price:
Negotiation
MOQ:
1KM
Delivery Time:
30 working days after received your payment
Brand:
Yiyuan
Product Description
795kg/Km Subsea Fiber Optic Heavy Duty Armoured Cable GYTA5333 4-144 Core Single Mode
| Basic parameters: | |||
| Country of Origin | China | Product name | armored fiber optic cable |
| Brand name | Yiyuan | Type | GYTA5333 |
| Fiber count | 4-144 core | Fiber mode | Single mode G652D |
| Weight | 261-795kg/km | Outer diameter | 14.2-22.3mm |
| Structure |
Loose tube stranded; Multi armor and multi jacket(sheath) |
Strength member |
Aluminum tape; Corrugated steel tape; Round steel wire |
| Sheath material | PE | Strength member | Phosphating steel wire |
| Operation temperature | -20~+60℃ | ||
| Other optional fiber | 9/125: G652D,G657 50/125 62.5/125 | ||
A-class optical fiber provide the high performance of transmission; PBT loose tube material has good hydrolysis resistance, the tube is filled with special ointment to protect the optical fiber; Phosphating steel wire as strength member to improve the good tensile strength performance; With good temperature characteristics; PE sheath anti-UV Three layers of armor and jacket,moisture-proof, crush resistant,durable;
