Product Description
In the GYTY53 cable, single-mode/multimode fibers are positioned in the loose tubes, the tubes are filled with water blocking filling compound.Tubes and fillers are stranded around the strength member into a circular cable core. Then the cable is completed with a PE sheath. Which is filled with the filling compound to protect it. After PSP is applied over the inner sheath, the cable is completed with a PE outer sheath.
Specification
|
Cable Type (Increased by 2 fibers) |
Fiber Count |
Tubes + Fillers |
Fiber in Tube |
Cable Diameter mm |
Cable Weight kg/km |
Tensile Strength Long/Short Term N |
Crush Resistance Long/Short Term N/100mm |
| GYTY53 2 ~36 | 2 ~36 | 6 | 6 | 12.6 | 184 | 1000/3000 | 1000/3000 |
| GYTY53 38 ~ 72 | 38 ~ 72 | 6 | 12 | 14.0 | 216 | 1000/3000 | 1000/3000 |
| GYTY53 74 ~ 96 | 74 ~ 96 | 8 | 12 | 15.7 | 260 | 1000/3000 | 1000/3000 |
| GYTY53 98 ~ 120 | 98 ~ 120 | 10 | 12 | 17.4 | 301 | 1000/3000 | 1000/3000 |
| GYTY53 122 ~ 144 | 122 ~ 144 | 12 | 12 | 19.0 | 354 | 1000/3000 | 1000/3000 |
| GYTY53 144 ~ 288 | 144 ~ 288 | 18 | 12 | 19.0 | 350 | 1000/3000 | 1000/3000 |
Characterisics
1. Excellent mechanical and temperature performance guaranteed by the accurate excess fiber length.
2. Critical protection to fibers.
3. Excellent crush resistance and flexibility.
4. The following measures are taken to ensure the water blocking performance of the cable:
- Single steel wire used as the central strength member
- Special water-blocking filling compound in the loose tube.
PSP moisture barrier
- 100% cable core filling and water-blocking material
