N08904 Stainless Plain Sheet Steel Metal Plate Corrosion Resistance
Common Trade Names
Alloy 904L, 904L Stainless
Specifications
ASME SB-625, ASME SB-649, ASME SB-673, ASME SB-674, ASME SB-677, UNS N08904
Available size :
|
Grade
|
904L
|
|
Thinckness
|
0.3mm-60mm
|
|
Widthness
|
50mm~2000mm or customized
|
|
Length
|
1000mm~8000mm or customized
|
|
Standard
|
JIS, AISI, ASTM, GB, DIN, EN
|
|
Material
|
904L/304/304L/316/316L/321/309S/904L/202/201/430/410/409 stainless steel, etc
|
|
Surface
|
2B,BA,HL,BK,NO.1,NO.4,8K,SB,etc
|
|
Certification
|
BV,ISO ,CE
|
|
Application
|
|
Features
Critical Crevice Corrosion Temperature*
| Alloy | 316 | 317 | 904L | AL-6XN® | 625 |
| Temperature, °F | 27 | 35 | 65 | 113 | 113 |
* ASTM procedure G-48, 10% ferric chloric solution
Applications
Air Pollution Control — scrubbers for coal-fired power plants
Chemical Processing — process equipment for the production of sulfuric, phosphoric, inorganic and organic acids and the production of phosphate-based fertilizers
Metallurgical Processing — pickling equipment using sulfuric acid
Oil and Gas Production — offshore process equipment
Pharmaceutical Industry — process equipment
Pulp and Paper — processing equipment
Seawater and Brackish Water — condensers, heat exchangers and piping systems
| Product Name | Nickel Alloy Plate/sheet inconel 600 601 625 X-750 718 825 |
| Material | Nickel Alloy / Monel/Inconel/Hastelloy/Duplex Steel/PH Stee |
| Shape | Plate, sheet Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet |
| Grade | Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L |
| Others: 253Ma,254SMo,654SMo,F50(UNS S32100)F60,F61,F65,1J22,N4,N6 etc | |
| Alloy : Alloy 20/28/31; | |
| Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g; | |
|
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,Hastelloy C-276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665 |
|
| Haynes: Haynes 230/556/188; | |
| Inconel Series: | |
| Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20; | |
| Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851, Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 / UNS N06600 / DIN W. Nr. 2.4816 |
|
| Incoloy: Incoloy 800/800H/800HT/825/925/926; | |
| GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044 | |
| Monel: Monel 400/K500/R405 | |
| Nitronic: Nitronic 40/50/60; | |
| Nimonic: Nimonic 75/80A/90/A263 ; | |
| Specification |
Strip: 0.05*5.0-5.0*250mm Wire: 0.01-10mm |
| Product Characteristics |
1.According to the preparation process can be divided into deformation superalloys, casting superalloys and powder metallurgy superalloys. 2.According to the strengthening mode, there are solid solution strengthening type, precipitation strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc.. |
| Standard | GB,AISI,ASTM,DIN,EN,SUS,UNS etc |
| Inspection | ISO,SGS,BV etc . |
| Application | High temperature components such as turbine blades, guide vanes, turbine disks, high pressure compressor disks,machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines |
| Packaging | 1. cases packed in wooden cases 2. paper packaging 3. plastic packing 4. foam packaging Packaging according to customer requirements or products |
| Delivery | 7-25days or according to the product |
| Payment | L/C,D/A,D/P,T/T,Western Union,MoneyGram,According to customer requirements payments for offline orders. |
