China C10200 Coil Copper And Copper Alloys for sale

C10200 Coil Copper And Copper Alloys

Price Negotiable

Price: 8-16 USD / kg

MOQ: 50kg

Delivery Time: 5-25 days

Brand: XINZHENG

Product Description

ASTM UNS C10100 99.99 Oxygen Free 5 ppm Copper Sheet

COPPER SHEET / COPPER PLATE Specification and Size

Item	99.9% Pure Copper Coil C11000 Copper Strip for Water Heater
Material	T1,T2,C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920, TP1,TP2,C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300, TU1,TU2,C12500,C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200, C21000,C22000,C23000,C24000,C26000,C27000,C27400,C28000,C33000,C33200, C34000,C34200,C35000,C35600,C36000,C37000,C37700,C37710,C38000,C44300, C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70600,C70620,C71000, C71500,C71520,C71640,C72200,etc.
Thickness	0.01-20mm
Width	6-1500mm
Length	2m,3m,5.8m, 6m, or as required.
Surface	mill,polished,bright,oiled,hair line,brush,mirror,sand blast,or as required.
Price Term	Ex-work, FOB, CFR, CIF, etc.
Payment Term	T/T, L/C, Western Union, etc.
Delivery Time	3-5 working days if this goods is stock goods.
	12-15 working days if this goods will be produced after order.
Package	Export standard package: bundled wooden box, suit for all kinds of transport,or be required.

Copper tube synonyms

COPPER PIPE , BRASS PIPE ,BRASS TUBE ,BRONZE TUBE ,BRONZE PIPE

Copper OFC, Oxygen-free Copper, Copper OFHC, Oxygen-free high thermal conductivity copper,

Copper OFE, Oxygen free electrolytic copper, Oxygen Free Electronic Copper, ASTM F68, Copper Alloy 101,

C101, C102, C10100, C10200 Copper O, High-conductivity copper, C-110, C11000,

C110 Electrolytic Tough Pitch (ETP) copper,

Cu-ETP, C122, C-122, C145, C-145, C147, C-147, O60 (soft / annealed) temper,

H00 (cold rolled), H01 (cold rolled, high yield), H02 (half hard) temper, H03 (three quarter hard) temper, H04 (full hard) temper

COPPER TUBE / COPPER PIPE PRODUT SHOWCASE

Outside diameter		wall Thickness	Nominal Weight (kgs)
(inch)	(mm)	(mm)	(15Meters)	(15.24Meters)
3/16	4.76	0.8	1.33	1.35
1/4	6.35	0.8	1.86	1.89
1/4	6.35	1	2.25	2.28
5/16	7.94	0.8	2.4	2.44
5/16	7.94	1	2.91	2.96
3/8	9.52	0.8	2.93	2.98
3/8	9.52	1	3.58	3.64
1/2	12.7	0.8	4	4.06
1/2	12.7	1	4.91	4.99
5/8	15.88	1	6.25	6.35
3/4	19.05	1	7.58	7.7
7/8	22.22	1	8.91	9.06

Cu materials/alloys

European standard

DIN standard (former)

ASTM

Typical properties/application

Manufacturing standard

Cu-ETP

CW004A

E-Cu 58

2.0065

C11000

standard alloy for electrical components, main appli-

DIN EN 13599

E-Cu 57

2.0060

cation in switchgear construction

DIN EN 1652

Cu-HCP Cu-PHC

CW021A CW020A

SE-Cu

2.0070

C10300

hydrogen-resistant, very high conductivity, easy to weld

DIN EN 13599

Cu-OF

CW008A

OF-Cu

2.0040

C10200

hydrogen-resistant, very high conductivity, very easy to weld

DIN EN 13599

Cu-OFE

CW009A

C10100

high purity, Cu 99.99% fur vacuum switching systems, targets

DIN EN 13604

Cu-DHP

CW024A

SF-Cu

2.0090

C12200

very easy to weld, without particular conductivity requirements

DIN EN 1652
DIN EN 1653 AD-2000W6/2

CuAg0,10P

CW016A

CuAg0,1P

2.1191

C10700

mould plates, commutator rings, electrodes

DIN EN 13599

CuCrZr

CW106

CuCrZr

2.1293

C18150

mould plates, welding equipment, furnace and mould engineering, heavy current engineering

DIN 17670

CuNi2Si

CW111C

CuNi2Si

2.0855

C18000

mould engineering, machine parts, die casting equipment

by arrangement

Products can be supplied by arrangement in compliance with other international standards such as BS, JIS and GOST.

Brass Physical Specifications
Alloy 260
ASTM B36
UNS Number C26000
Temper	Annealed	H01	H02	H03	H04	H06	H08	H010
Temper	Annealed	Quarter Hard	Half Hard	3/4 Hard	Hard Temper	Extra Hard	Spring Temper	Extra Spring
Tensile Strength	N/A	49-59	57-67	64-74	71-81	83-92	91-100	95-104
*Rockwell B - Scale	N/A	40-65	60-77	72-82	79-86	85-91	89-93	91-95
*Superficial 30T	25-38	43-60	56-68	65-72	70-74	74-77	76-78	77-79
*Rockwell F - Scale	65-76
Grain Size OS035	.025-.050
*For Reference Only
