EN 10346 HDP Galvanized Steel Coil Zinc Coated Steel Sheet
EN 10346 Cold Rolled Base Zinc Coating Hot-Dip Galvanized Steel Coil / HDP Steel Coi For Building Materials
The applications of steel sheets in daily life are constantly expanding. Coated steel products such as Xinzheng's galvanized steel sheets have enjoyed particularly strong growth in fields where corrosion resistance and cost reduction by process omission are important. Our coated steel sheets offer superior economy in construction and automotive applications, electric appliances, and electronic equipment. We jave made an effort for development and production of various kinds of hot dip galvanized products thanks to most modern facilities and long time accumulated technologies. Xzh steel 's wide range of hot dip galvanized products include pure zinc coated, alloy coated, and unique high corrosion resistance chemically treated steel sheets which respond to the increasingly advanced and diverse needs of changing markets. As the results, Xzh steel has got sincere reliance from the domestic and overseas customers. Understanding the excellent characteristics of Xzhsteel 's products aiming future progress, sincere patronage from the customers are welcomed.
- Corrosion Resistance - High-grade pure zinc coupled with uniform coating ensures highest Red Rust resistance.
- Uniform & Superior Zinc Adhesion - Superior Zinc adhesion is achieved through electrolytic cleaning of steel substrate before coating.
- Absolute Flatness - Absolute flatness is possible through 'Wet Skin Passing', which ensures improved surface texture and superior shape retention.
- Optimum Malleability & Ductility - Best substrate steel quality is achieved by applying close controls on process parameters right from Raw Material [Iron ore & Coal] stage to steel production ensuring desired quality right from Commercial to IF grades of steel.
- Superior Paint Adhesion - True zero spangled surface with RA factor varying between 0.8 - 1.4 ensures superior paint adhesion, better finish due to absence of spangles/crushed spangles, which also lowers paint requirement and hence, lowers the cost.
Galvanized Coil / GI Coil Synonyms
Zinc Coated Galvanized Coil / GI Coil Specication ,Surface Finish, Size Range
| Hot-dip Galvanized Steel Coil | |||||||
| CNS 1244 2013 | JIS G 3302 2019 | ASTM A653M 2017 | AS1397 2011 | EN 10346 2015 | |||
| Specifications | Hot-rolled Base: | Cold-rolled Base: | Hot-rolled Base: | Cold-rolled Base: | DS | G1~G3 | DX51-52-53D |
| SGHC | SGCC | SGHC | SGCC | DDS | G250 | S220GD | |
| SGHD | SGCD | SGHD | SGCD | CS TYPE A, B, C | 300 | (250 | |
| SGH | 1~3 | SGH | 1~3 | FS TYPE A, B | 350 | 280 | |
| 340 | SGC | 340 | SGC | SS GRADE | 400 | 320 | |
| 400 | 340 | 400 | 340 | 33(230) | 450 | 350 | |
| 440 | 400 | 440 | 400 | 37(255) | 550 | 550) | |
| 490 | 440 | 490 | 440 | 40(275) | |||
| 540 | 490 | 540 | 490 | 50(340)CLASS 1~3 | |||
| 570 | 570 | 80(550)CLASS 1~3 | |||||
| Thickness of Base Steel (mm) | 1.2~4.60 | SGCD1~3: 0.27~2.0mm | 1.2~4.60 | SGCC,SGC340: 0.18~3.0mm; | DS: 0.27~2.0mm; | G1: 0.19~4.50mm; | DX51D: 0.19~4.50mm; |
| SGCC/SGC: 0.19~2.0mm | SGCD1~3: 0.25~2.0mm; | DDS: 0.25~2.0mm; | G2&G3: 0.27~2.0mm; | S220~550GD: 0.19~4.6mm; | |||
| SGC400, 440: 0.229~3.0mm; | CS/FS: 0.19~4.50mm; | G250~550GD: 0.19~4.6mm; | S250GD: 0.18~2.02mm; | ||||
| SGC490: 1.8~3.0mm; | SS GRADE 33~80: 0.19~4.50mm; | G300: 0.229~2.3mm; | DX52D: 0.295~2.0mm; | ||||
| SGC570: 0.229~2.2mm | CS TYPE A, B, C, Grade 33, 37: 0.18~3.0mm; | G350: 0.229~3.0mm; | DX53D, 54D: 0.25~2.0mm; | ||||
| FS TYPE A, B: 0.295~2.0mm; | G450: 0.6~3.0mm; | S280GD, S350GD: 0.229~3.0mm; | |||||
| Grade 40, 50: 0.229~3.0mm; | G500: 1.1~2.5mm; | S320GD: 0.229~2.3mm; | |||||
| Grade 55(380): 0.35~3.0mm; | G550: 0.229~2.2mm | S550GD: 0.229~2.2mm | |||||
| Grade 60(410): 0.47~1.6mm; | |||||||
| Grade 65(450): 0.6~3.0mm; | |||||||
| Grade 80: 0.229~2.2mm | |||||||
| Coating Mass: | Z08~Z60 | Z08~Z60 | Z90~Z600 | Z100~Z600 | Z100~Z350 | ||
| Regular Spangle | |||||||
| (thickness > 0.60mm) | |||||||
| Minimized (Zero) | |||||||
| Spangle | |||||||
| Surface Finish | Regular Spangle, Minimized (Zero) Spangle, Extra-Smooth | ||||||
| Surface Treatment | Chromating, Oiled, Resin Coated (Anti-Fingerprint), or Green Treatment (Environmentally Friendly Anti-Fingerprint) | ||||||
| Remarks | 1. Tolerance for thickness, width, flatness and so on conforms to individual product specification. | ||||||
| 2. All products with thickness 2.0mm and under can be skin passed. | |||||||
| 3. The specification for thicknesses under 1.6mm for hot-rolled base metal according to JIS G3302 will be the same as for thicknesses 1.6mm. | |||||||
| 4. The coil inside diameters can be either 508mm or 610mm. The maximum coil outside diameter is 2000mm. | |||||||
| 5. Please make inquiries to our Sales & Marketing Division for products with special specifications. | |||||||
| 6. Coating mass beyond the specifications above can be provided by Yieh Corp. upon mutual agreement between customers and us. | |||||||
| 7. Coating mass Z08, Z09 and Z90 only apply for cold-rolled base metals. | |||||||
Available Size
| Product Name | Base Type | Thickness (mm) | Width (mm) |
| Hot-dip Galvanized Steel Coil | Cold-rolled Base | 0.17~3.00 | 670~1650 |
| Hot-rolled Base | 1.20~4.60 | 670~1300 |
The table above shows the widest range of product dimensions. For a detailed
acceptable order range, please contact US.
JIS G 3302 2019 Chromating,Coating Galvanized Steel Coil Application
Galvanized steel is well suited for applications that need rust-resistant materials at a competitive price,
ultraviolet light protection and easy integration with other materials. Industries that use hot-dipped
galvanized steel products include:
Automotive
Pipe and Tubular
Outdoor Recreation
Agriculture
Construction
Galvanized Coil / GI Coil display and package
