C101 Jis H3250 Copper And Copper Alloys Round Bar Copper Rod
COPPER ROUND BAR / COPPER ROD / METAL COPPER ROUND OVERVIW
Copper, Brass & Bronze might look the same but have distinct properties and applications. Zinc & Copper are combined to make Brass. Bronze is an alloy of primarily copper with a tint of tin or phosphorus or manganese or aluminium or silicon. While brass is recognised for its ductility, bronze concedes a greater hardness. Both brass & Bronze are utilised in architectural and commercial purposes. Bronze is also utilized in musical instruments as well. Though, brass is smooth and polished, bronze is more porous and faint. These can be fabricated and cut in many diverse shapes, grades and sizes.
Kian Huat Metal is acknowledged & appreciated in the industry as leading Square Bar/Round Bar Supplier and Manufacturer. We have a broad spectrum of brass/copper/bronze round bars & square bars. Strengthened by a team of ingenious experts, we are qualified to render the clients with a remarkable collection of Round Bars/Square Bars. Our trustworthy team of experts conducts the complete manufacturing and production means in assent with the industry standards and criteria
COPPER ROUND BAR SPECIFICATION Diameter Dimension
| BS | ISO | EN | DESCRIPTION | |
|---|---|---|---|---|
| C101 | Cu-ETP | CW004A | Electrolytic, tough pitch, high conductive copper | |
| C103 | Cu-OF | CW008A | Oxygen free high conductivity copper | |
| C111 | Cu-S | CW114C | Sulphur copper (free machining) | |
| C109 | Cu-TEP | CW118C | Tellurium copper (free cutting) | |
| C101 | Cu-Ag-2 | CW011A | Silver-bearing Copper | |
| C101 | Cu-Ag-3 | CW012A | Silver-bearing Copper | |
| C101 | Cu-Ag-4 | CW013A | Silver-bearing Copper | |
| CC102 | CuCr1Zr | CW106C | Copper Chrome Zirconium | |
| Copper Bar Grades | C14500 Tellurium Copper Alloy, C145 Tellurium Copper Rod and Bar, Alloy 101 Copper Round Rod, Alloy 110 Copper Round Rod, Alloy 122 Copper Round Rod, Alloy 145 Copper Round Rod (C10100, C11000, C12200, C14500) |
|---|---|
| Specification | ASTM F68, ASTM B301, ASTM B187 |
| Copper Round bar size | Diameter: 3mm~800mm |
| Copper Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Copper Square bar size | 4mm*4mm~100mm*100mm |
| Copper Flat bar size | Thickness: 2mm~100mm |
| Width: 10mm~500mm | |
| Copper Hex Bar size | 2mm~100mm |
| Copper Billet Size | 1/2" to 495mm Diameter |
| Copper Rectangles Size | 33mm x 30mm to 295mm x 1066mm |
| Finish | Bright, Polish, Bright, Rough Turned, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Hot Rolled Pickled or Sand Blasting Finished, Cold Drawn, Bright, Polished, Hairline |
| Condition | Cold Drawnd Pulished Cold Drawn Centreless Ground & Polished, Annealed round bar |
| Technique | Copper Hot Rolled, Cold Rolled, Cold Drawn, Forged Round Bar, Rod |
| Copper Bar Type | Drawn Bar, Rolled Bar, Forged Bar, GFM Forged Bar, Open Die Bar, Forged Stepped Shafts, Forged Flat Bar, Forged Square Bar |
| Also Check price list of | Inconel Round Bar, Inconel 625 Round Bar, Inconel 718 Round Bar, Hastelloy Round Bar, Monel Round Bar, Titanium Round Bar, Copper Nickel Bar, Stainless Steel Round Bar |
| Form | Round, Rod, Precision Ground Bar, Square, Round Rod, Hollow, Hex (A/F), Triangle, Rectangle, Threaded, T-Bar, Half Round Bar, Flat Bar, Rings, Blocks, Billet, Ingot, I/H Bar, Angle, Channel Bar, Profiles, Forging Etc. |
| Our Copper Round Bar conforms to NACE MR0175/ISO 15156 | |
| Type | SIZES (mm) | SIZES (Inches) | ISO Tolerance |
|---|---|---|---|
| Cold Drawn and Polish | 3.00 – 75.00 | 1/8” – 3.00” | h8-h9-h10-h11, ASTM B187 |
| Cold Drawn and Ground | 10.00 – 75.00 | 5/6” – 2.50” | h8-h9-h10-h11 |
| Peeled and Polished | 40.00 – 150.00 | 1.50” – 6.00” | h11, ASTMA-484 h11-DIN 1013 |
| Peeled and Ground | 20.00 – 50.00 | 3/4″ – 2.00” | h9-h10-h11, ASTM B187 |
Most popular Specifications
BS 1400 LG2
JIS H3250 C1100
JIS H3250 C3604
NS/CDA: UNS. C17510, CDA 1751
ASTM: B441
QQ/MIL: SAEJ 461,463
RWMA: Class 3
DIN: 2.0850, CW110C
|
Size
|
KG/Metre
|
|
1/4" DIA
|
0.28
|
|
5/16" DIA
|
0.44
|
|
3/8" DIA
|
0.63
|
|
1/2" DIA
|
1.13
|
|
5/8" DIA
|
1.76
|
|
3/4" DIA
|
2.54
|
|
7/8" DIA
|
3.45
|
|
1" DIA
|
4.51
|
|
11/8" DIA
|
5.71
|
|
11/4" DIA
|
7.05
|
|
13/8" DIA
|
8.53
|
|
11/2" DIA
|
10.1
|
|
15/8" DIA
|
11.9
|
|
2" DIA
|
18
|
|
21/4" DIA
|
22.8
|
|
21/2" DIA
|
28.2
|
|
4" DIA
|
72.2
|
|
10.0mm DIA
|
0.7
|
|
12.0mm DIA
|
1.01
|
|
16.0mm DIA
|
1.79
|
|
20.0mm DIA
|
2.8
|
|
25.0mm DIA
|
4.37
|
|
30.0mm DIA
|
6.29
|
|
40.0mm DIA
|
11.2
|
|
50.0mm DIA
|
17.5
|
Copper Round Bar Delivery condition
- Cold drawn Copper Round Bar
- The strain Hardened
- Peeled, center less ground & polished
- Turned & rough polished Copper Cold Drawn Round Bar
- Trailed center less ground & polished
- Peeled and polished Copper Bar
- Smooth Turned & Polished Copper Round Bar
- Solenoid quality
- Annealed Copper Black Bar
- Hardened strain Copper Rod
COPPER ROUND BAR STORAGE , APPLICAITON , PACKAGE
Owing to the ages of experience as Round Bar Supplier & Manufacturer, xinzheng special metal is qualified to trade and fulfil a broad range of Galvanized Steel & Aluminium Round Bar/Square Bar to our esteemed clients. Our Round Bars and Square Bars have excellent strength, Sturdiness, and are cut to precise dimensions. We are acknowledged as a pre-eminent Square Bar/Round Bar Manufacturer and Supplier with high durability.
