SS416 Hot Rolled Steel Strips Thickness 3mm AMS 5505 UNS S41600 Steel for automatic machine tool processing
416 Stainless Steel Precision Strip Coils UNS S41600 Ba Annealed 1/2 Hard Temperedoverview
Alloy 420 a martensitic stainless steel that provides good corrosion resistance similar to alloy 410 with an increase strength and hardness. It is magnetic in both the annealed and hardened conditions. Maximum corrosion resistance is attained only in the fully hardened condition.
416 Strip Coil / Rolls Equivalent Materials
DIN 1.4005 DIN X12CrS13 AFNOR Z11CF13 AFNOR X12CrS13 BS 416S21 BS X12CrS13 AISI 51416 AISI S41600 SAE 51416 SAE 416 SAE S41600 JIS SUS416 EN X12CrS13 EN 1.4005 GB Y1Cr13 ASTM 416 ASTM Grade 6F (416) UNS S41600
Specifications AMS 5610 Type II, ASTM A 314, ASTM A 484, ASTM A 582, Federal Spec QQ-S-764B, UNS S41600
Grade: 416
Standard: ASTM/EN/JIS
Thickness: 0.03mm-3.0 mm
Width: 15mm-600 mm
Length: coil type or it can be produced as customer requirements
Surface Finish: NO.1, 2B, 2H
Edge: Mill Edge, Slit Edge, Deburred Edge, Round Edge, V Type Edge
| Tempered Condition : | |
| ANNEALED CONDITION | TEMPERED 1/16 HARD |
| Tempered 1/8 Hard | TEMPERED 1/4 HARD |
| TEMPERED 1/2 HARD | TEMPERED 3/4 HARD |
| TEMPERED FULL HARD | Tempered Extra Hard |
| Annealed | 2B /BA/ MIRROR / HL / SATIN / No.1 |
SS416 Hot Rolled Steel Strips Application
Type 416 stainless steel is used forshafts, axles, gears, screws, bolts and any part that requires considerable machining. Should not be used for vessels under high pressures.
Applications
- Axles, shafts and gears
- Automatic screw machine parts
- Firearms production
- Pump and valve components
416 Stainless Steel Precision Strip Coils UNS S41600 Ba Annealed 1/2 Hard Tempered Technical datasheet
| Typical Analysis | Grade 416 |
| Chrome | 12.00-14.00 |
| Nickel | |
| Carbon | .15 max. |
| Manganese | 1.25 max. |
| Silicon | 1.00 max. |
| Molybdenum | .06 max. |
| Sulphur | .15 min. |
|
Mechanical Properties Brinell Hardness |
(Annealed) 155 |
| Tensile–KSI | 75 |
| Yield–KSI | 40 |
| Elongation in 2"-% | 30 |
| Red. in Area-% Min | 60 |
|
Welding Characteristics |
Poor brittle welds |
|
Machining Compared to B1112 Screw Stock |
90% |
|
Specifications AISI |
416 (Bar) 416 |
| ASTM | A581, A582 |
| AMS | 5610 |
General Q and A Questions
Q: Would you provide samples For free?
A: Yes. with on stock specification We provide samples For Free. Freight charge collect
Q: What information should i provide to source for the right products?
A: Material grade, width, thickness, coating and Purchase quantity, Expected lead time, etc
Q: What are the shipping ports?
A: Under normal circumstances, we ship from Shanghai, Tianjin, Qingdao, Ningbo ports, you
can choose other ports according to your needs.
Q: About product prices?
A: Prices vary from period to period due to cyclical changes in the price of raw materials.
Q: How long does your delivery time take?
A: In general, our delivery time is within 5-45 days, and may be delayed if the demand is extremely
large or special circumstances occur.
Q: Can I visit your location?
A: Of course, we welcome customers from all over the world to visit our factory. However, some
of the plants are not open to the public.
Q: Does the product have quality inspection before loading?
A: Of course, all our products are strictly tested for quality before packaging, and unqualified products will be destroyed. We provide All Original Mill test certificate and support third party inspection.
Q: How to pack the products?
A: The inner layer has a waterproof paper outer layer with iron packaging and is fixed with a fumigation
wooden pallet. It can effectively protect products from corrosion during ocean transportation.
Q: What is your working time?
A: In general, our online service time is Beijing time: 8:00-22:00, after 22:00,
we will reply to your inquiry during the next working day.
