ASTM E8 0.23mm Copolymer Laminated Steel Tape For Fibre Cable Shielding
Thickness 0.23mm Copolymer Laminated Steel Tape For Fibre Cable And Electric Cable Armouring, Shielding
It consists of steel tape coated on one side with an adherent ethylene copolymer.the copolymer is an acrylic acid-based copolymer, such as ethylene-acrylic acid, ethyl-methyl-acrylic acid, PE, ionomers, and the like. Ethylene-Acrylic Acid Copolymer (EAA) was chosen as the standard material for the bonding adhesive in our company, This unique thermoplastic is unsurpassed for forming a strong heat seal bond between aluminum and low and medium density polyethylene in cable applications. The steel is low carbon electronic chrome-coated steel tempered to T-2 condition for excellent formability and fabrication characteristics.
Technical data sheet
| ITEM | UNIT | INDEX | TOLERANCE | |
| Length | m | 1000-5000 | +/-50 | |
| Width | m | 12-800 | +/-0.5 | |
|
Thickness steel |
mm | 0.10-0.20 | +/-0.010 | |
| Co-polymer(EAA) | mm | 0.058 | +/-0.013 | |
| Total thickness | mm | 0.20-0.30 | +/-0.015 | |
| Chromium on Steel | G/M2 | 0.08-0.34 | ||
| Tensile Strength | MPA | 310-390 | ||
| Elongation at Break | % | ≥20 | ||
| Peel Strength between Steel and Plastic Coating | N/cm | ≥6.13 | ||
| Heat Seal Strength | N/cm | ≥17.5 | ||
| WaterResistance68+/-1℃,168h Peel Strength | N/cm | ≥6.13 | ||
| Filler/Floodant Resistance 68+/-1℃,168h | SP | --- | No Delamination | |
| WT-103 | --- | No Delamination | ||
| Dielectric Strength DC 2KV,1min | --- | No breaking | ||
| Corrosion Resistance | grade | 8 |
FAQ
Q: Would you provide samples For free?
A: Yes . with on stock specification We provide samples For Free . Freight charge collect
