100L silicon carbide ceramics Wet Sand Grinding Mill especially For White Color Paint
30L 50L 100L Non Ex-Proof Water Base White Color Paint Horizontal Grinding Sand Mill With Ceramics Inner Chamber
Water based paint is relatively green compared with oil based paint, and the explosion performance can be lowered to choose non ex-proof motor when grinding. While the white color has different requirement. Some require the color is pure white. Most steel material can change the white color with grey after grinding many times, because of the metal contamination. Ceramics materials is valid to avoid metal contamination, to ensure the white color unchangable. Meanwhile the temperature control is better, it's obviously different especially for the seasons, places and countries with high temperature. In addition, the assembly structure owns two patent technologies, ensuring ceramics inner chamber not to be crashed. At last, ceramics has greater wear resistance, to make sure the longer work life of grinding chamber.
Technical specification:
| ”super” SP series of horizontal grinding sand mill | ||||
| Type | Working Volume | Power | Grinding Beads | Throughput |
| SP30 | 30 | 30 | 0.3-3.0 | 70-700 |
| SP50 | 50 | 37 | 0.3-3.0 | 100-1000 |
| SP100 | 100 | 55 | 0.3-3.0 | 300-3000 |
Configuration instructions information of bead mill machines
| No | Main parts | SP series | Notes |
| 1 | External vessel | SUS 304 stainless steel | |
| 2 | Inner grinding vessel | silicon carbide ceramics | different mateials are also optional |
| 3 | Material of Dispersing shaft | 40Cr with hard chromium plating | |
| 4 | Material of Dispersing disk (agitator disk) | wearable steel,SUS 304 stainless steel | |
| 5 | end covers | SUS 304 stainless steel | |
| 6 | discharge manner and material | Static discharge, stainless steel | |
| 7 | Mechanical seal | Intelligent double mechanical seal | |
| 8 | Feeding pump | G1",G1.5” ARO diaphragm pump; | Ingersoll Rand |
9 | Dispersing structure | pure disk type, disk combined with turbine,or disk combined with turbine and pins.
| we can recommend which structure is more suitable. |
| 10 | Alarming system | applied for each machines or for your choice | |
Ceramics inner chamber
Assembly structure
If need more detailed information, please don't hesitate contact us, Also Warmly welcome to visit us.
