1100kg Forklift Side Shifter Attachments 1555mm Opening
Accessories for forklift side fork with 915mm fork
Parameter
| Capacity@ Load Center (Kg@mm) |
Model No. | Mounting Class | Opening Range (mm) |
Fork Length A(mm) |
Frame Width B (mm) |
Overall Height H (mm) |
Vertical Center of Gravity CGV(mm) |
Weight (kg) |
Effective Thickness ET(mm) |
Horizontal Center of Gravity CGH(mm) |
| 1100@600 | CFS15D-001A | II | 435-1555 | 915 | 865 | 635 | 175 | 250 | 175 | 163 |
| 1100@600 | CFS15D-002A | II | 435-1555 | 1065 | 865 | 635 | 165 | 259 | 175 | 191 |
| 1100@600 | CFS15D-003A | II | 435-1555 | 1220 | 865 | 635 | 150 | 268 | 175 | 226 |
Product Description
CFS15D-001A Fork Length 915mm, Frame Width 865mm, Overall Height 635mm, Vertical Center of Gravity 175mm
CFS15D-002A Fork Length 1065mm, Frame Width 865mm, Overall Height 635mm, Vertical Center of Gravity 165mm
CFS15D-003A Fork Length 1220mm, Frame Width 865mm, Overall Height 635mm, Vertical Center of Gravity 150mm
Options
* Fork size
* Various installation categories are available
* User defined opening range
Remark:
1. Obtain the actual capacity of forklift and accessories from the forklift manufacturer.
2. Two sets of additional oil circuits are required on the forklift.
3. The opening range is the space between the tips of the two arms.
4. The fork clamp can be equipped with a special arm as required.
5. Provide different fork requirements as required.
Other size available on request.
Applicable Industries
Hotels, clothing stores, building materials stores, machinery maintenance stores and manufacturers
Can be customized according to size
Customized solutions:
Carton Clamp
Block Clamp
Bale Clamp
Roll Clamp
......
all kinds of attachment
