11.1V 2.2ah Lithium Iron Phosphate Power 18650 Battery Pack Rechargeable
18650/11.1V 2.2ah Rechargeable Lithium Iron Phosphate Power Battery Pack
>Main Features
1. Using lithium iron phosphate battery technology process, higher safety;
2. 100% DOD charge and discharge under standard conditions, more than 3000 cycles;
3. Built-in automatic protection device to prevent over-charge, over-discharge,over-current and over-temperature;
4. Maintenance-free, can replace lead-acid batteries;
5. Light weight, about 40%~50% of the weight of lead-acid batteries.
>Products parameters
| Battery pack Model | 18650 /11.1V/2.2Ah | |
| Nominal Voltage | 11.1V | |
| Nominal Capacity | 2000mAh | |
| Rated Power | 22.3Wh | |
| Charge method | CC/CV | |
| Max. Charge voltage | 12.8V | |
| Over-current protection current | 2A | |
| Over-charge protection voltage | 12.6V | |
| Charge Current | 0.2C (standard); 0.5C (quick) | |
| Discharge protection voltage | 9.0V | |
| Charging Temperature | 0~45°C | |
| Discharge Temperature | -20~+60ºC | |
| Storage Condition | Temperature | -20~60ºC |
| Humidity | 60±25% | |
| Lithium Battery Protection | Short circuit protection, overcharge, overprofit protection, overcurrent protection, temperature protection, balance, etc. | |
| Dimensions | Max. L70mm*W56.6mm*H19.3mm(customizable) | |
| Weight | Approx 480g | |
2. Portable electronics,
3. Laptop Battery Cell s,
4. Customized Battery Pack Solutions,
5. Military, electric vehicle, and aerospace applications
6. Solar Lawn, Remote Control
7. Electric tools,electric vehicles, toys,
8. Wind energy system,landscape energy storage,
9. Backup Power Supply, Medical Device and so on.
To ensure proper use of the battery please read the manual carefully before using it.
Handling
1. Do not expose to, dispose of the battery in fire.
2. Do not put the battery in a charger or equipment with wrong terminals connected.
3. Avoid shorting the battery
4. Avoid excessive physical shock or vibration.
5. Do not disassemble or deform the battery.
6. Do not immerse in water
7. Do not use the battery mixed with other different make, type, or model batteries.
8. Keep out of the reach of children.
Charge and discharge
1. Battery must be charged in appropriate charger only.
2. Never use a modified or damaged charger.
3. Do not leave battery in charger over 24 hours.
Storage
1. Store the battery in a cool, dry and well-ventilated area.
2. Disposal
Regulations vary for different countries. Dispose of in accordance with local regulations.
