Rechargeable sealed lead acid battery 12V 200Ah For Solar Storage UPS
Rechargeable sealed lead acid battery 12V 200Ah For Solar Storage UPS
> Main Features
1.Maintenance free rechargeable sealed lead acid battery
As it is valve-regulated sealed lead acid battery.sealed and glass mat is used .acid is trapped inside.
so refilling is not needed and is leak proof.
5. Low self discharge
The self –discharge rate for FOBERRIA Sealed Lead Acid Battery is about 2-3% per month at room.
temperature compared with 20-30% for other common battery systems.
6. Longer service life
Used thick and massive calcium grate ensure that FOBERRIA battery has a longer service life over 10years.
7. High discharge rate
Since the internal resistance is low .the battery can provide high rate of discharge.
8. Wide operation temperature range
VRLA Rechargeable Sealed Lead Acid Battery capacity is rated at 25°C, and will operate from 15°C +50°C when it is fly charged Ambient temperature is 25°C.Service life will be more efficient under 15’C to 25”C .
| Battery Model No. | FBR12-200 | |
| Nominal Voltage | 12V | |
| Capacity | 20HR(5.25V) | 200Ah |
| (25ºC) | 10HR(5.25V) | 176Ah |
| 1HR(4.80V) | 124Ah | |
| Dimension | Length | 522±2mm |
| Width | 238±2mm | |
| Height | 218±2mm | |
| Total height | 221±2mm | |
| Approx. Weight | 59.5kg±4% | |
| Terminal type | F13 | |
| Internal resistance(Fully charged,25ºC) | Approx 3.5mΩ | |
| Capacity affected by | 40ºC | 102% |
| Temperature(20HR) | 25ºC | 100% |
| 0ºC | 85% | |
| -15ºC | 65% | |
| Self-discharge(25ºC) | 3month | Remaining Capacity:91% |
| 6month | Remaining Capacity:82% | |
| 12month | Remaining Capacity:65% | |
| Nominal operating temperature | 25ºC±3ºC(77ºF±5ºF) | |
| Operating | Discharge | -15ºC-50ºC(5ºF-122ºF) |
| temperature range | Charge | -10ºC-50ºC(14ºF-122ºF) |
| Storage | -20ºC-50ºC(-4ºF-122ºF) | |
| Float charging voltage (25ºC) |
13.5 to 13.8V Temperature compensation:-18mV/ºC |
|
| Cyclic charging voltage (25ºC) |
14.5 to 15V Temperature compensation:-30mV/ºC |
|
| Max charging current | 60A | |
| Max discharging current | 1600A(5sec.) | |
| Designed floating life(20ºC) | 10years | |
| Component | Positive plate | Negative plate | Container | Cover | Separator | Electrolyte | Safety valve | Terminal |
| Raw material | Lead dioxide | Lead | ABS | ABS | AGM | Sulfuric acid | Rubber | Copper |
1. Solar power system(off-grid solar power system, solar street light system, solar garden light system);
2. Wind Power System;
3. UPS and computer backup power;
4. telecommunication system;
5. Power station System;
6. Railway System;
7. Emergency lighting system;
8. Automatic control system;
9. Alarm system for fire protection, security.
| F.V/Time | 5min | 10min | 15min | 30min | 60min | 2h | 3h | 4h | 5h | 10h | 20h |
| 3.20V | 17.2 | 10.9 | 8.51 | 4.79 | 2.95 | 1.61 | 1.12 | 0.92 | 0.78 | 0.43 | 0.228 |
| 3.30V | 16.7 | 10.6 | 8.3 | 4.7 | 2.9 | 1.6 | 1.11 | 0.92 | 0.78 | 0.42 | 0.227 |
| 3.40V | 16 | 10.13 | 7.99 | 4.55 | 2.83 | 1.59 | 1.1 | 0.91 | 0.77 | 0.42 | 0.226 |
| 3.50V | 15.3 | 9.69 | 7.72 | 4.44 | 2.77 | 1.56 | 1.09 | 0.9 | 0.77 | 0.42 | 0.225 |
| 3.60V | 14.4 | 9.15 | 7.31 | 4.28 | 2.69 | 1.52 | 1.06 | 0.88 | 0.75 | 0.41 | 0.221 |
>Constant Power Discharge Characteristics(Watt,25ºC)
| F.V/Time | 5min | 10min | 15min | 30min | 60min | 2h | 3h | 4h | 5h | 10h | 20h |
| 3.20V | 63.9 | 40.9 | 32.3 | 18.3 | 11.4 | 6.29 | 4.42 | 3.66 | 3.12 | 1.7 | 0.91 |
| 3.30V | 62 | 39.7 | 31.5 | 17.9 | 11.2 | 6.25 | 4.39 | 3.64 | 3.11 | 1.7 | 0.91 |
| 3.40V | 59.5 | 38.1 | 30.4 | 17.4 | 10.9 | 6.2 | 4.36 | 3.62 | 3.08 | 1.69 | 0.91 |
| 3.50V | 56.9 | 36.4 | 29.3 | 17 | 10.7 | 6.1 | 4.33 | 3.59 | 3.06 | 1.68 | 0.9 |
| 3.60V | 53.7 | 34.4 | 27.8 | 16.3 | 10.4 | 5.95 | 4.2 | 3.48 | 2.97 | 1.65 | 0.88 |
A1: Tell us your demand, then our sales will recommend a suitable battery for you.
Q2. Do you have any MOQ limit?
A2: Yes, we have MOQ for mass production, it depends on the different model numbers. 50-500pcs sample order is available.
Q3. Is it OK to print my logo on the product?
A3: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
A4: The capacity of a battery, in Ahs, is a dynamic number that is dependent on the discharge current. For example,
Q5. Are you a battery manufacturer, and do you produce the plate by yourself ?
A5: Yes, we are a professional battery manufacture in Fujian Province, China. And we produce plates by ourselves.
Q6. How to proceed with an order?
A6. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places a deposit for formal order.
Fourthly We arrange the production.
