Flood OPzS Lead Acid Battery 2V 300ah Longlife Low Self Discharge
Flood OPzS Lead acid battery long life battery 2V 300ah-3000ah super longlife 20+years
>Overview
OPzS series is a flooded Lead Acid battery that adopts Tubular Plate technology to offer high reliability and performance. The Battery is designed and manufactured according to IEC60896-11 standards and with die-casting positive spine and patent formula of active material. OPzS series with more than 20 years floating design life at 25℃ and is even more suitable for cyclic use(solar/wind energy, traction etc) under extreme operating conditions.
>Main Features
1. OPzS battery series is Valve Regulated Lead Acid battery adopting immobilised GEL and Tubular Plate technology,
offering high reliability and stable performance.
2. The OPzS battery series is designed and manufactured according to DIN standards, with die-casted positive grid and patented active
material formula, they exceed the DIN standard values.
3. They offer 20 years design life in float service at 25"C and are more suitable for cyclic use under extreme operating conditions.
4. Suitable for power supply in telecommunication, photovoltaic wind energy storage and UPS applications.
| Voltage | Voltage | Capacity | Internal resistance(mm) | Terminal Type |
Dry Weight (Kg) |
Wet Weight (Kg) |
|||
| (V) | (Ah) | Length | Width | Height | Total Height | ||||
| OPzS 200 | 2 | 200 | 103 | 206 | 355 | 410 | F12 | 13 | 17.5 |
| OPzS 250 | 2 | 250 | 124 | 206 | 355 | 410 | F12 | 15 | 20.5 |
| OPzS 300 | 2 | 300 | 145 | 206 | 355 | 410 | F12 | 17.5 | 24 |
| OPzS 350 | 2 | 350 | 124 | 206 | 471 | 526 | F12 | 21 | 28 |
| OPzS 420 | 2 | 420 | 145 | 206 | 471 | 526 | F12 | 23 | 32 |
| OPzS 490 | 2 | 490 | 166 | 206 | 471 | 526 | F12 | 26.5 | 37.5 |
| OPzS 600 | 2 | 600 | 145 | 206 | 646 | 701 | F12 | 35 | 47 |
| OPzS 800 | 2 | 800 | 191 | 210 | 646 | 701 | F12 | 48 | 64 |
| OPzS 1000 | 2 | 1000 | 233 | 210 | 646 | 701 | F12 | 58 | 78 |
| OPzS 1200 | 2 | 1200 | 275 | 210 | 646 | 701 | F12 | 68 | 92 |
| OPzS 1500 | 2 | 1500 | 275 | 210 | 796 | 851 | F12 | 80 | 111 |
| OPzS 2000 | 2 | 2000 | 397 | 212 | 772 | 827 | F12 | 110 | 152 |
| OPzS 2500 | 2 | 2500 | 487 | 212 | 772 | 827 | F12 | 132 | 185 |
| OPzS 3000 | 2 | 3000 | 576 | 212 | 772 | 827 | F12 | 159 | 222 |
1. High expected service life
2. Long cycle stability
3. Best compatibility
4. There is no need to add water for a long time to achieve maintenance free
5. Short circuit can be prevented even during installation;
1. Applications
2. Telecom
3. Security Systems
4. Medical Equipments
5. UPS systems
6. Railroad Utilities
7. Photovoltaic Systems
8. Renewable Energy System
| Component | Positive plate | Negative plate | Container | Cover | Separator | Electrolyte | Safety valve | Terminal |
| Raw material | Lead dioxide | Lead | ABS | ABS | PVC-SiO2 | Sulfuric acid | EPDR | Copper |
>Competitive Advantage
1. Sealed construction,safty and no leakage;
2. Maintenance-free,convenient for installation;
3. Broad operating temperature range;
4. High capability,high energy density;
5. Low self-discharge tate,more deep cycle times;
6. Long service life,excellent recharge and discharge time than other batteries.
>Cerificate
