380V 50Hz 3 Phase HRC CRC ST37 Steel Coil Slitting Line
Price:
USD
MOQ:
1set
Delivery Time:
90 working days
Brand:
MAZS
Product Description
1. Product Description:
Steel Coil Slitting Line with Stably Speed or can be orderd by user auto rotary shear machine
2. Technical data:
- Material of coils: carbon steel, color steel, galvanized steel and etc
- Strip thickness: (0.2~1) mm
- Strip width: 600mm
- Inner diameter of coils: Φ508mm
- Max. Outer diameter of coils: Φ1500mm
- Max. Coil weight: 8000kg
- Recoiling block: Ф508 x 700
- Recoiler motor: AC 37KW
- Slitter shaft: Ф180 x 700
- Slitter motor: AC 22KW
- Material of disc cutter: ID180mm x OD300mm x 8/10mm, 6CrW2Si, HRC58-60.
- Slitting speed: (0~50) m/min, adjustable
3. Specifications:
| Model | Thickness | Coil Weight | Finished slit | Max Slitting speed | |
| MA-1 x 600 | 0.2-1mm | 100-600mm | Max 8T | Min. 20mm | 50m/min |
| MA-2 x 1300 | 0.3-2mm | 300-1300mm | Max 15T | Min. 25mm | 80m/min |
| MA-3 x 1600 | 0.3-3mm | 500-1600mm | Max 20T | Min 25mm | 100m/min |
| MA-4 x 1600 | 0.4-4mm | 500-1600mm | Max 30T | Min 30mm | 80m/min |
| Note: The data in the form just as reference according to general ranges, we always design and make each line according to each customer’s specific requirements, so each customer can buy his own well-content line from us. | |||||
