China MAZS ( 0.2-1)x600 Slitting line is used for cold rolling，galvanized coil, decoiling, slitting and recoiling for sale

MAZS ( 0.2-1)x600 Slitting line is used for cold rolling，galvanized coil, decoiling, slitting and recoiling

Price Negotiable

Price: USD

MOQ: 1set

Delivery Time: 90working days

Brand: MAZS

Product Description

1. Product name:

MAZS ( 0.2-1)x600 Slitting line is used for cold rolling,galvanized coil, decoiling, slitting and recoiling.

2. Process flow:

V-shaped preparation table - coil car - decoiling frame - material uncoiling device - pinch and leveler - hydraulic shearing machine - storage pit - guiding centering device - slitting machine - side scrap device - storage pit - tension device - recoiling- discharge coil car

3.Specification form of Metal Coil Slitter:

Model	Thickness		Coil Weight	Finished slit	Max Slitting speed
MA-1 x 600	0.2-1mm	100-600mm	Max 8T	Min. 20mm	50m/min
MA-2 x 1300	0.3-2mm	300-1300mm	Max 15T	Min. 25mm	80m/min
MA-3 x 1600	0.3-3mm	500-1600mm	Max 20T	Min 25mm	100m/min
MA-4 x 1600	0.4-4mm	500-1600mm	Max 30T	Min 30mm	80m/min
Note: The data in the form just as reference according to general ranges, we always design and make each line according to each customer’s specific requirements, so each customer can buy his own well-content line from us.
